Leeboy 6150 Asphalt Pavers
6150 ASPHALT PAVERS
6150 ASPHALT PAVERS
The LeeBoy 6150 wheeled asphalt paver was truly designed with the paving professional in mind. With a quicker travel speed, this paver delivers a quality mat while easily maneuvering from point to point.
Given traditional LeeBoy style and operation, the operator has a choice of working in a high-deck or low-deck configuration which can greatly benefit visibility depending on the application. Improved easy-to-reach service compartments allows quick access for regular maintenance requirements.
INFORMATION
BRAND
Leeboy
PRODUCT TYPE
Asphalt Pavers
LBP EQUIVALENT
150D
PRODUCTION
Made in USA
FUEL CAPACITIES
36 gallons
HYDRAULIC CAPACITIES
36 gallons
ENGINE
- Kubota turbocharged diesel
- Tier 4 Final – 74hp (55 kw) @ 2,200 RPM
OPERATOR’S CONTROLS
-High deck/low deck configuration -Dash panel is movable from left to right and contains all machine controls -Pivot steer and posi-trac -Equipped with auger and conveyor bypass -Color graphic control screen with digital readouts. Review and monitor system vitals including: oil pressure, hour meter, fuel gauge, volt meter, water temp, tachometer, hydraulic oil temp, engine diagnostics
PAVING WIDTHS
Variable paving widths up to 15’
PAVING WIDTHS
Machine has variable paving widths up to 15’
DIMENSIONS
- Length : 16’ 6”
- Height : 7’ 8”
- Width : 8’ 6” transport 10’ 7” hopper wings down
TOTAL WEIGHT (WITH SCREED)
17,550 lbs
WASHDOWN TANK CAPACITIES
7 Gallons
HOPPER
- Conveyor Fed
- Hopper Size : 7 ton
- Hopper Height : 22”
- Side wings hydraulically fold in or out
DOWNLODS
↓ Product Brochure
↓ Product Manual 1
↓ Product Line Card
↓ Product Manual 2
↓ Product Specifications
PAVING DEPTHS
Depth : 0” to 6”
MAINTENANCE
Regular Maintenance Requirements
GALLERY
