Nelskamp S Concrete Roof Tiles
S CONCRETE ROOF TILES
S CONCRETE ROOF TILES
With its flowing "S" form, this tile creates soft-look rooftops.
The rounded cut edges emphasise the visual impression and have the positive side-effect of greater storm safety.
INFORMATION
BRAND
Nelskamp
PRODUCT TYPE
Roof Tiles
MATERIAL
Concrete
PRODUCTION
Made in Germany
DIMENSIONS
- Total Width : 33.2 cm
- Total Length : 42.0 cm
OVERLAP
Approx. 7.5 - 10.6 cm
TILLING LENGTH
31.4 - 34.5 cm
TILES REQUIRED PER SQM
10.0 pcs.
TILLING WIDTH
30.0 cm
USE
Outdoor
STANDARD ROOF PITCH
22°
WEIGHT PER TILE
4.5 kg
WEIGHT PER SQM
45.0 kg
TILES PER SQM
Approx. 10 pcs.
PROJECTION
Overlapping side interlock and triple base ribbing for optimum protection
INTERLOCK
Produced in compliance with DIN/EN 490/491 with raised longitudinal interlock and much better quality characteristics than stipulated
COMPRESSIVE STRENGTH
Impermeable to water, resistant to frost and deformation, dimensionally precise with high compressive strength
COLOURS & SURFACES
COMPARISON OF CONCRETE ROOF TILE SURFACES
-The low-porosity surface structure prevents dirt particles from gaining a hold on LONGLIFE roof tiles – the rain simply washes them off. -Longlife technology delivers maximum resistance to uv radiation and weather effects. The result: permanent colour fastness.
-Longlife roof tiles are extremely wear-resistant. Their optimised surface protects the roof tiles, including the exposed edge. -The powerful self-cleaning effect also minimises the formation of lichen, moss and algae.
CLIMALIFE
The ClimaLife roof tiles with titanium dioxide in the surface neutralise heating, traffic and industrial pollutants.
They interact with daylight to neutralise up to 90% of harmful substances. Even without sunlight, a neutralisation rate of up to 70% can be achieved. Titanium dioxide is a photocatalyst – i.e. it isn’t consumed in the chemical reaction. The rain takes care of the rest by simply washing away the now harmless substances.
ClimaLife – environmental protection under a clean roof.
- Ideal for urban roofs
- Controlled quality: TXActive®
- Individual character with a natural matt surface
- The first roof tile to extract exhaust fumes from the air
- The rain washes off dirt particles and atmospheric fine dust
- Active degradation of pollutants by photocatalysis – a roof-life long
LONGLIFE
Longlife concrete roof tiles with high colour fastness and self-cleaning effect
Smooth – including the exposed edge: the fine surface of longlife roof tiles opens up a bright future for nelskamp roofs. The advanced longlife technology means that the exposed edge now also has low porosity for permanent protection of the entire rooftop – and a visually harmonious look. Longlife roof tiles stay clean for a very long time – so they always look like new. Dirt, algae and moss cannot gain a hold, and rain acts like a shower for the roof.
