Zehnder Pumpen D-SWH Water System
D-SWH Water System
D-SWH WATER SYSTEM
Overcomes gravity drainage problems and enables basement showers
INFORMATION
BRAND
Zehnder Pumpen
PRODUCT TYPE
Water System
PRODUCT NUMBER
21547
MAX. FLOW RATE
3.9 m³/h
APPLICATION
Pump Suitable For Shower And Washbasin
ART.NO
21547
HEAD UP TO [M]
7.0
INPUT POWER P1
250 W
MAX. HEAD
7.5 m
PRESSURE OUTLET
DN 32
PRODUCTION
Made in Germany
VOLTAGE [V]
230
DOWNLOAD
↓ Data sheet
CHARACTERISTICS
PRODUCT BENEFITS
- Low switch-on height
- Versatile use (shower & washbasin) due to 2 inlets at the bottom side
DIMENSIONS
- Height : 167 cm
- Width : 177 cm
- Length : 293cm
Q MAX
4.2
H MAX
4.0
MATERIAL
- Material container : PP
- Seal motor: Shaft seal
- Seal pump : Mechanical seal
- Material motor housing : PA 12 30% GF
- Material pump housing : PA 66 15% GF
- Material motor shaft: stainless steel AISI 303
SCOPE OF DELIVERY
Non-Return Valve
C [ΜF]
10
POWER P2
200
FEATURES
Mit Schwimmerschalter
TECHNICAL DRAWINGS
DIMENSIONS PACKING
- Height : 290 cm
- Width : 260 cm
- Length : 240 cm
PUMPED MEDIUM
- Clear water
- Rainwater
- Waste water
MODEL
- Protection Grade Ip 44
- Pressure Outlet Dn 32
- Operating temperature 35°C
- Switch-on height 55 mm
- Compact size for discreet installation
- Sound pressure level (1m) at 46 dB
- Installation height shower tray 12 cm
- Prepared shower inlet DN 40, usable on both sides
- Tank ventilation through activated carbon filter
