Knauf Ceiling Solution Armstrong MetalWorks R-H 200 Metal Ceiling Tile
ARMSTRONG METALWORKS R-H 200 METAL CEILING TILE
ARMSTRONG METALWORKS R-H 200 METAL CEILING TILE
Armstrong MetalWorks R-H 200 is a versatile custom metal plank design suitable for regular & staggered patterns.
INFORMATION
BRAND
Knauf Ceiling Solutions
PRODUCT TYPE
Ceiling Tile
FIRE REACTION
Class 0 / Class 1, BS 476, Part 6 & 7
FEATURES
Suitable for large open plan / circulation areas
DOWNLOADS
↓ Warranty
↓ Data Sheet
↓ Mainline Brochure
COLLECTION
Armstrong
PRODUCTION
Made in Italy
APPLICATION AREAS
- Office
- Education
- Healthcare
- Hospitality and retail
- Exterior and Seismic application
- Transportation (including Light Rail)
USE OF TOOLS
All panels are fully accessible without the use of tools.
AVAILABLE
Available in a variety of sizes, perforations & finishes.
FURTHER FEATURES
- Good acoustic properties.
- Maintenance friendly system.
- Easy access to the ceiling void.
- Versatile system and simple design.
- Concealed grid for a monolithic effect.
- Ease of installation (alignment) and fully demountable.
MATERIAL & OPTIONS
SUSPENSION COMPONENTS
- J-Bar
- U-Profile
- J-Bar Splice
- Plug-in Clip
- Wall Anchor
- J-Bar Hanger
- U-Profile Splice
- J-Bar Security Clip
PANEL DIMENSIONS
Typical panel dimension range from 300mm to 600mm wide upto 3000mm long. The RH200 system features larger size panels and gasketed 3mm joints. Our Armstrong Architectural Specialities project management team is available to assist in project design for custom Jobs.
MATERIAL
Galvanized Steel - 0.6mm & 0.7mm Aluminum - 1.0mm
PAINTED FINISH
Factory-applied polyster paint (interior), PVDF (exterior)
BENEFITS
-3mm reveal joint detail -Interior and exterior custom solutions in metal
-Choice of planks & curved canopies -All panels are fully accessible without the use of tools -Factory cutouts available on request for recessed light and spinklers -Accessible system utilizes J-Bar suspension with rectangular hook-on (RH) panel -Panel dimension 300mm - 600mm in width & upto to 3000mm in length with a variety of other sizes available -Recommended panel size ratio is maximum 1:2 (not ideal for 600mmx600mm) - Most versatile custom system for metal plank design
