MONTREAL - OPEN TO FRONT FIREPLACE
MONTREAL - OPEN TO FRONT FIREPLACE
Exclusive, stylish and high quality are the common denominators for Decoflames built-in mirrors - here the model that is open to the front.
Montreal is a stylish and minimalist built-in bio fireplace of the highest quality. Montreal is an obvious choice of bio fireplace for new construction or as part of a renovation project in an older home. All bio fireplaces from Decoflame are designed and produced in Vestbjerg, North Jutland.
Montreal is available in different variants, this one is for open front. This specific model is ideal if you want full focus on the fireplace. Fireplace cozy with modern tones that create an aesthetic atmosphere.
The model is available with manual and electronic bio-burner, as well as Hybrid Mist. The electronic models can be controlled either directly via the display on the fireplace, with the supplied remote control or via our Decoflame app. See datasheet and examples of principle drawings below.
INFORMATION
USE
Using the CEVB (Controlled Ethanol Vapour Burning) technology, Decoflame has created Montreal with the Denver e-Ribbon Basic burner, a simplified automatic burner with built-in casing. Featuring the e-Ribbon Fire™ burning system, it is suitable where safety and ease operation are in focus.
BRAND
Decoflame
PRODUCT TYPE
Fireplace
HEAT-ZONE
SIZES
- 800 X 400 X 300
- 1000 X 400 X 300
- 1200 X 400 X 300
TOPPLATE (BURNER) FINISH
- Other finishes on request
- Standard : Black powder coated top-plate
- Optiona l: Stainless steel and any RAL colour
DOWNLOADS
↓ Datasheet Montreal Manual Burner
↓ Datasheet Montreal with Denver Basic
↓ PRINCIP Montreal Front Right Left - conv 1000x400x300mm - 1x DB920
↓ Princip montreal front right left conv. 1000x400x300mm - 1x MB800
↓ Princip montreal front right left conv. 1000x400x300mm - 1x HB920
COLORS
Black
POWER SUPPLY
220V - 240V, 50 Hz 5A
TECHNICAL DIAGRAM
MONTREAL CAN ALSO BE ORDERED WITH
-Manual burner -Denver e-Ribbon Basic burner (non-convertable) -MTM (made-to-measure) with Denver e-Ribbon burner
FEATURES
- 6 flame levels (1-5 + ECO-Wave)
- 8mm aluminium casing and baseplate
- Fuel Level Indicator / Flame Level Indicator
- No chimney required - no smoke, ash or soot
- Glass screen ordered (Full and/or low glasses)
- Safety chamber
- Remote control
- Bluetooth / App
- e-Ribbon™ technology
- Safety sensors / Safety chamber
LOCATION UNDER TV SCREEN
It is NOT recommended to place TV screens or valuable paintings over the fireplace as the rising hot air can damage the materials. If you decide to use a construction containing a TV screen over the bio fireplace, the following instructions must be followed, otherwise consult your retailer or Decoflame.
![Decoflame Montreal - Open To Front Fireplace](http://{"type":"application/jidipi-edit","data":"<figure class=\\"jdp-reset jdp-image-figure\\" data-ce-tag=\\"image-figure\\"><div class=\\"jdp-mask\\" data-ce-tag=\\"mask\\"><img src=\\"https://upload.jidipi.com/posts/d00096808/4-03s-AR1.png\\" data-image-id=\\"65fd22c0ce6d238af2444ede\\" srcSet=\\"https://upload.jidipi.com/fit-in/420x0/posts/d00096808/4-03s-AR1.png 420w, https://upload.jidipi.com/fit-in/700x0/posts/d00096808/4-03s-AR1.png 700w, https://upload.jidipi.com/fit-in/900x0/posts/d00096808/4-03s-AR1.png 900w\\" data-image-name=\\"4-03s.png\\" width=\\"646\\" height=\\"423\\" loading=\\"lazy\\" class=\\"jdp-image jdp-reset\\"/></div></figure>"})
TECHNICAL INFORMATION
| DATA | 720 MM | 920 MM | 1120 MM |
|---|---|---|---|
| Flametray size | 500mm | 700mm | 900mm |
| Capacity | 4L | 5.8L | 7.2L |
| Fuel consumption | 0.3 - 0.6 l/h | 0.4 - 0.8 l/h | 0.6 - 1 l/h |
| Burning time | 7 - 20h | 7.5 - 20.8h | 7.3 - 20h |
| Heat output | 1.2 - 3.2 kWh | 1.6 - 4.3 kWh | 2.1 - 5.7 kWh |
| Net weight | 19.5kg | 22kg | 26kg |
| Minimum room size | 64m3 | 89m3 | 115m3 |
GLASS SHIELD
Decoflame strongly recommends installing glass shields in order to protect the flame from draught, while keeping it vivid.
-Model A : comes with one low glass.
-Model B : comes with either two low glasses or one full glass and one low glass.
-Model C - E : can be ordered with low glass. We recommend it as illustrated for the best result regarding design and operation
INSTALLATION
-Step 1 : Make sure that the dimensions of the cut-out corre- spond to the measurements indicated in the technical drawing received with your fireplace. Everything must be in level.
-Step 2 : Connect the fireplace to an electrical power supply.
-Step 3 : Recess the fireplace into the wall cut-out and place the frame according to the indications in the User’s Manual.
-Step 4 : Place the glass screen/s on to the top pin holders.
-Step 5 : Turn on the fireplace. Fill in the right amount of bioethanol by verifying the level on the indicator.
-Step 6 : Start the fireplace by pressing the Play/Start button on the control panel.
