Usg Mars™ Acoustical Ceiling Panels
MARS™ ACOUSTICAL CEILING PANELS
MARS™ ACOUSTICAL CEILING PANELS
Item : 86185
Fine-textured panels. Sustainable aesthetics and high performance. These acoustical ceiling tiles are also mold- and sag-resistant.
Offering a combination of sustainable aesthetics and outstanding performance, these panels are specially manufactured to maximize sound control and anti-sag performance.
Mars™ Acoustical Panels are fine-textured, mold resistant and offer superior sag resistance, high light reflectance values and excellent noise reduction.
Their durability, performance, easiness to clean and attractiveness make them an ideal choice for corridors, department stores, reception areas, lobbies and general office spaces.
INFORMATION
BRAND
Usg
PRODUCT TYPE
Ceiling Panel
ASTM E84
- Fire Rating : Class A
- Flame Spread : 25 or less
- Smoke Developed : 50 or less
ASTM E1264 CLASSIFICATION
-ASTM E1264-22 Type IV, Form 1 & 2, Pattern E & G -ASTM E1264-23 Type A, Form A2.1, Pattern E & G
WEIGHT
1.01 lb./sq. ft.
PANEL SIZE
24 in. x 24 in.
THERMAL RESISTANCE
R-2.2
LIGHT REFLECTANCE
Up To 0.90
RECYCLED CONTENT
69 %
ASTM E84 AND CAN/ULC S102 SURFACE-BURNING CHARACTERISTICS
- Class A
- Flame spread : 25 or less
- Smoke developed : 50 or less
MAINTENANCE
Can be cleaned easily with a soft brush or vacuum. To clean panel, use a clean, white cloth with water or a mild detergent and wipe surface.
ITEM CODE
86185
FIRE RATING
Class A
SOUND ATTENUATION
35 CAC
SOUND ABSORPTION
0.75 NRC
APPLICATIONS
- Classrooms
- Patient Rooms
- Mall Interior Spaces
- Administrative Offices
- Guest Rooms and Suites
- Convention and Meeting Rooms
- Department Stores and Boutiques
- Galleries and Exhibit Spaces
-Lobbies and Reception Areas
- Nurseries and Birthing Rooms
- Executive Areas, Conference Areas and Board Rooms
- Media Centers, Music Rooms and Libraries
SUSTAINABILITY
- Recycled Content : 69%
- Greenguard Certification : Yes
- Voc Emissions : Low-emitting
THICKNESS
3/4 in.
COLOR
White
MATERIAL
Mineral Fiber
EDGE
Square Edge
HIGH RECYCLED CONTENT
USG classifies High Recycled Content as greater than 50%. Total recycled content is based on product composition of postconsumer and preconsumer (postindustrial) recycled content per FTC guidelines.
CLIMAPLUS™ WARRANTY PERFORMANCE
Contains a broad-spectrum antimicrobial additive on the face and back of the panel that provides resistance against the growth of mold and mildew. Includes sag-resistance performance.
LOW EMISSIONS (VOC)
Third party (greenguard gold) certified for low-emitting performance, meets california department of public health’s (cdph) standard method v1.2 - 2017 (ca section 01350). ‘certificates of compliance’ for low voc emissions are available on usg.
MAIN FEATURES
Mars™ Acoustical Panels are durable, long-lasting panels manufactured using a unique process that maximizes sound and anti-sag performance, producing high (.75) noise reduction coefficients (NRC) and solid ceiling attenuation class (CAC) performance. The non-directional pattern ensures consistent appearance.
- Class A
- Impact and scratch resistant
- Washable and scrubbable finish
- Compatible with Logix™ Integrated Ceiling Systems
- Achieves FDA standards for smoothness, durability and cleanability
- High light-reflective finish (LR - .90) reduces light fixtures and energy use
- Non-directional, monolithic visual reduces installation time and waste
- Coordinates visually with Halcyon™ panels for open/closed plan applications
- ClimaPlus™ 30-year lifetime system warranty against visible sag, mold and mildew
- Available in High Recycled Content formulations to help maximize LEED recycled content contribution
- Low-emitting product meets CA Specification 01350, California Department of Health Services Standard Practice for the testing of VOC emissions
