Usg Halcyon™ Logix™ Acoustical Panels
HALCYON™ LOGIX™ ACOUSTICAL PANELS
HALCYON™ LOGIX™ ACOUSTICAL PANELS
Fine-textured panels with exeptional noise reduction for open-plan offices. For use with Logix™ Integrated Ceiling Systems.
With Halcyon™ Logix™ Acoustical Panels you can turn your ceiling's lighting and utilities into stunning design elements by integrating them into your ceiling plan with this system. Halcyon™ Logix™ Acoustical Panels are lightweight fiberglass panels that promise a lifetime of exceptional noise reduction and excellent light reflection.
Fine-textured, mold resistant with superior sag resistance, these panels allow you to meet building requirements while transforming your ceiling with a sleek modern finish that is ideal for virtually any commercial interior.
INFORMATION
BRAND
Usg
MATERIAL
Fiberglass
EDGE
Fineline
THICKNESS
1 in.
LIGHT REFLECTANCE
0.90
APPLICATIONS
- Classrooms.
- Patient Rooms.
- Mall Interior Spaces.
- Administrative Offices.
- Guest Rooms and Suites.
- Galleries and Exhibit Spaces.
- Lobbies and Reception Areas.
- Nurseries and Birthing Rooms.
- Convention and Meeting Rooms.
- Department Stores and Boutiques.
- Media Centers, Music Rooms and Libraries.
- Executive Areas, Conference Areas and Board Rooms.
ASTM E84
- Fire Rating : Class A
- Flame Spread : 25 or less
- Smoke Developed : 50 or less
ASTM-E1264-CLASS
XII: Glass fiber base with membrane-faced overlay, E: Lightly textured; G: Smooth, Form 2: Water-Felted
FIRE RATING
Class A
RECYCLED CONTENT
40%
SOUND ATTENUATION (CAC)
20
MOLD & MILDEW RESISTANCE
Yes
PANEL SIZE
12 In. X 96 In.
SOUND ABSORPTION (NRC)
0.95
MAIN FEATURES
Halcyon™ Logix Acoustical Panels are durable, long-lasting panels manufactured using a unique process that maximizes sound and anti-sag performance, producing high (up to 0.90) noise reduction coefficients (NRC) and solid ceiling attenuation class (CAC) performance. The non-directional pattern ensures consistent appearance.
- High postconsumer recycled content.
- Compatible with Logix™ Integrated System.
- Monolithic, structured ceiling visual using standard components.
- Washable and scrubbable finish — impact and scratch resistant.
- High sound absorption with an NRC of up to 0.95 and an AC of up to 200.
- High light-reflective finish (LR-0.90) reduces light fixtures and energy use.
- ClimaPlus™ 30-year limited system warranty against visible sag, mold and mildew.
- Coordinates visually with Mars™ Logix™ Acoustical Panels for open/closed-plan applications.
