Coveringsetc Eco-Terr® Tiles
Eco-Terr® Tiles
ECO-TERR® TILES
Future-friendly - Resilient - Stunning
Eco-Terr® is an environmentally friendly, high-quality terrazzo product that combines aesthetic and mechanical characteristics.
Our Future-Friendly™ terrazzo collection of tiles and slabs come in various colors with aggregates that range from micro to large formats and have various applications, including flooring, outdoor terrace, pool, pavers, counters, vanities, walls, exterior facades, furniture, and industrial design.
INFORMATION
BRAND
Coveringsetc
PRODUCT TYPE
Floor Tiles
STANDARD SIZES TILES
- 16x16x5/8"
- 24x24x3/4"
MODULUS OF RUPTURE
- Astm : C-99
- Results : 1,550 psi
FLEXURAL STRENGTH
- Astm : C-880
- Results : 1,973 psi
COLLECTION
Eco
PRODUCTION
Made in USA
USE
Floor
DOWNLOAD
Indoor
STANDARD FINISHES
Honed, Polished, Microlinen (with the highest DCOF in the market).
COMPRESSIVE STRENGTH
- Astm : C-170
- Results : 14,000 - 24,000 psi
ASTM
C-1028
RESISTANCE TO FIRE
Class 0
FREEZE-THAW
- Astm : C-666
- Results : None (300 cycles)
RESULTS
- Polished
- Honed
- Sandblasted
DESIGN
Industrial
QUALITY
High
FOUNDATION (SCREED OR CEMENT PLASTER)
-Prepare the screed or the plaster using cement mortar and wait its ageing until it reaches a residual humidity < 2% (waiting time: about 1 week for each cm of thickness). The screed must be thicker than 5 cm and respect the existing joints. -Before the laying, check the screed and the plaster suitability. These must be: insulated, dry, stable, solid, compression-resistant, sufficiently flat and free from loose material, dust, greases, oils, waxes, paints, detaching agents and any other items which may reduce adhesion. -Correct any irregularity with levelling and auto-levelling products, taking care to verify the perfect planarity of the plane which mustn’t have level differences higher than 2 mm.
GLASS AND MOTHER-OF-PEARL
-These elements differ in kind from the stone and for this reason single pieces of glass or mother-of-pearl may come off from the tiles, especially polishing the floor after the installation. In this case, fill eventual holes with suitable fillings for natural stone, on sale. The same can happen with the grains chips, in this case act in the same way indicated for the glass and mother-of-pearl. -Pay greater attention during the installation of tiles bigger than 24x24 inches, because bigger is the dimension of the tiles, higher is the risk of non-homogeneous planarity among them.
POST-LAYING TREATMENT
On dry and clean surface, apply a stain resistant impregnating hydro-repellent protection (such as FILA MP/90) or oil-repellent that doesn’t alter the aesthetic appearance of the tiles (such as FILAFOB). In alternative to the highly-protective treatment, it is possible to apply a coat of floor-finishing wax (such as VENEZIANA produced by FILA company) with a brush, a rag or with a suitable applicator.
Before a highly-protective treatment (recommended for floors exposed to high risk such as bars, rotisseries, restaurants, and in any place where the tiles may be stain with oil or mechanical oil) check that the floor is perfectly cleaned, in the contrary proceed before in cleaning the tiles with a degreasing detergent (such as FILA PS/87 diluted 1:10 with water).
CARE AND MAINTENANCE
CARE AND MAINTENANCE
To maintain surface luster, apply standard cleaning methods and use neutral detergents. Avoid cleaning products that contain acid (even when diluted), alkaline detergents, strong solvents and paint strippers. Cleaning can be simply done by wet mopping with a neutral detergent; then rinse thoroughly with clean water and let dry. To restore waxed surface gloss, coat periodically with a solution of the original finish wax diluted with water.
STORAGE
Do not leave materials outdoors since climatic conditions could affect the material causing damage to the surface or finish. ECO-TERR® is to be stored indoors. Once received it is advised to install materials promptly. Do not leave materials in storage for any length of time as moisture and light can alter condition of materials. Long term storage could cause discoloration or fluorescence, especially in lighter colors. ECO-TERR® is made of natural re-cycled stone components. The technical data may vary somewhat with each color blend.
PRODUCT INFORMATION
No two tiles are alike. The allure of consistent irregularity is one of the popular characteristics which create the allure of natural beauty by the blend of component materials that comprise ECO-TERR®. It is recommended that tiles be laid side by side prior to installation to assure an even color blend. Glass and mother-of-pearl are elements that differ in structure from the stone chips. Upon occasion one or more can become dislodged from the surface.
This can happen during the polishing process. These fissures can be evened out with suitable natural stone surface fillers. After installation some tiles may appear to lack uniform coloring. This is a natural phenomenon related to the evaporation process. When freshly installed, the humidity absorbed by the tiles from the adhesive can vary in tone from center to edges. It is destined to disappear during the drying process.
LAYING AND FILLING
LAYING AND FILLING
-Spread the adhesive on the foundation and lay ECO-TERR® on the wet adhesive before it forms the superficial pellicle. In case of high temperatures and ventilation, the open time of the adhesives (indicated in the specifications) can notably change. Before the laying, we suggest you to plunge the tiles in clean water for a few seconds and then drip the excess of water away, in order to guarantee a safer grip between the tile and the foundation. Carefully press in order to get a flawless adhesion and level the tiles with care and precision, to avoid differences in level among the tiles. Any excess adhesive which comes to the surface during laying must be removed immediately with a wet sponge, to prevent damages to the surface.
-The width of the laying joints (grouts) must comply with the European standards (width at least 2 mm, so that the sealant can penetrate to the required depth at all points). In any case, the dimensions of the tiles and the thermal expansion coefficient could determine the choice of joints having a different width, especially for outdoor flooring. Existing expansion joints must coincide with joints in the tiles, and subdivision joints must be provided (for great surface panels of approx. 170 sq ft), always following the suggestion of the person in charge for the laying.
-Laying must be carried out using adhesives specially developed for laying stone and cement agglomerates. As an indication, we can suggest the following adhesives: FLEX white, H40RAPID or H40MARMOREX (produced by company KERAKOLL) or other products with equal technical characteristics, to use following the instruction of the supplier company, also in relation to the weather situation. -The filling of joints must be performed while the adhesive is not yet completely hardened, using professional and colored fillers like FUGABELLA (KERAKOLL) or similar products with color as similar as possible to the color of the tile. The cleaning of the filler must be done within the right time (while still fresh) by using a sponge and clean water.
FINISHES
FINISHES
