ROMA-3 GRATING FENCES
ROMA-3 GRATING FENCES
Roma-3 has a rectangular aperture and is the most popular type of grating fence for schools, colleges, commercial premises and municipal areas.
It is made with a 25x3mm flat bar which provides excellent rigidity and durability.
In addition to the standard panel, a narrow width closing panel will be provided to suit the end of a fence run.
INFORMATION
BRAND
Lang+Fulton
PRODUCT TYPE
Fence
APPLICATION
Suitable for vertical applications such as balconies and balustrading.
MESH (C/C)
62×132 mm
STANDARD PANEL WIDTH
1992 mm
DETAIL
An RHS post is supplied as standard; alternative posts include flat bar and CHS. Roma-3 fences can also be customised to feature curved or waved tops, decorative rails and finials, ornamental or laser-cut motifs.
UNICLASS
Ss_25_60_05_05 Balustrade and guarding systems
STANDARD PANEL HEIGHTS
620, 1194, 1326, 1458, 1722, 1986, 2118, 2382, 2646, 2910 mm
RHS POST
50×3, 60×40, 80×40, 100×50 mm (depending on height)
ORIENTATION
Round bars set to the inside of the enclosed area.
FIXING
Fixing lugs for a bolted panel-to post-connection.
FINISH
Hot-dip galvanized. Hot-dip galvanized and polyester powder coated, RAL.
Guidance for specification option:
-Insert colour requirement. -To BS EN ISO 1461 and polyester powder coated to BS EN 1722-16 in any RAL colour. -Polyester powder coating is a multi-stage process which applies thermo-setting resins, producing a superior finish to painting.
POST FOUNDATIONS
-Ground fixing (concrete mix).
-Base plates for fixing to a concrete foundation. -Off-set over top of wall. -Anchoring within wall pockets.
PRODUCTION
Made in United Kingdom
COUNTRY OF MATERIAL ORIGIN
Europe
DIMENSIONS (LXWXH)
Bespoke
MATERIAL
Steel
STANDARD
To BS 1722-14.
POSTS
Mild steel S235JR.
PANELS
Vertical flat bars and horizontal round bars, framed top and bottom with flat bars, mild steel S235JR.
COLORS
- Grey
- Beige
- Black
- Blue
- Bronze
- Brown
- Copper
- Gold
- Green
- Red
- Silver
- White
- Other
- Yellow
CAWS
-Q40/30 Proprietary fencing
-Q40/430 Proprietary fencing
-Q40/126 Open mesh steel panel security fencing -Q40/27 Open mesh steel panel general purpose fencing -Q40/125 Open mesh steel panel general purpose fencing
FIXING TO PARENT STRUCTURE
Swing-hinged single or double leaf, bi-folding, pivot and sliding gates are made with Roma-3 infill panels to match.
PROCESS OF PRESSURE LOCKING
Panels and posts are supplied hot-dip galvanized with an optional polyester powder coating in any RAL colour. All grating fences are made in compliance with BS 1722-14.
RECYCLABILITY
100%
RAILS
- Not required.
- Hand rail.
SYSTEM ACCESSORIES
- Wood finials.
- Steel finials.
- Not required.
- Entry/ exit controls.
- Ornamental motifs.
- Laser cut panels.
