MOTION SOLID STACKWALL
MOTION SOLID STACKWALL
Our solidSTACKWALL > Motion is an innovative system that embraces automated operation and acoustic control for swift partitioning and privacy.
Automated locking and drop-seal mechanisms are activated when the panels are pushed next to each other, maximizing sound isolation and improving operating speed.
The top-hung solid material panels travel individually along an upper track and store into a pre-designed parking area.
For a streamlined appearance with minimal hardware exposure, the top-hung track can be concealed within the ceiling, allowing the panels to stack out of sight when parked.
This system offers users a refined partition system that creates acoustic and visual privacy while maximizing visual connection between adjoining spaces.
INFORMATION
BRAND
Carvart
PRODUCT TYPE
Stackwall
HARDWARE DIMENSIONS
HPL Panel Thickness: 4-3/16”, 4-5/16”, 4-15/16”
ACOUSTIC OPTIONS
CREATE with CARVART and combine insulation options for a highly acoustic system that fits your needs.
- Panel Type 1 : Single Panel + Single Gaskets STC – 41, 47,50
- Panel Type 2 : Single Panel + Double Gaskets STC – 55
- Panel Type 3 : Double Panel + Double Gaskets Stc – 57
COLLECTION
Motion
PRODUCTION
Made in NewYork
PANEL WIDTHS (OVERALL MAXIMUM)
Glass/MDF: Maximum 47-1/4”. Maximum run lengths (operable or fixed panels): Unlimited.
ACOUSTIC PROPERTIES
- MDF + HPL: 57dB [Rw] (for 4-15/16” panels)
- MDF + HPL: 55dB [Rw] (for 4-3/16”, and 4-5/16” panels)
APPLICATIONS
Space division between offices, conference rooms or flex-spaces.
PANEL TYPES
Fixed and Movable panels can be combined to create multiple configurations for various uses across a movable wall.
PANEL HEIGHTS (OPAQUE PANEL MAX. HEIGHTS)
- Type 100 : 137-3/4 ” (MDF+HPL)
- Type 800 : 255-15/16” (MDF+HPL)
- Type 1000 : 255-15/16” (MDF+HPL)
ADD-ON DESIGN OPTIONS
- Single and double doors.
- Range of acoustic isolation levels.
- Multi-directional/corner/angled configurations .
- Top-structure/suspension sytem available on request .
MDF + HPL FINISHES
- HPL Colors
- HPL Metallic
- HPL Wood Finishes
- HPL Colored Textures
- HPL Textures/Patterns/Fabrics
BENEFITS
-Semi-automatic hardware increases speed of operation and precision of seals -Wide-ranging acoustic and privacy options, seam details and panel connections -Minimal look with thin, aluminum profiles -Optional pre-engineered top structure support solution for taller spaces above finish ceiling -System durability and long-term integrity -Turnkey integrated project services
CONTROL
Swift Partitioning And Privacy
CREATES
Acoustic And Visual Privacy
CHARACTERISTICS
Determined by selected glass thickness and type, Sound Transmission Class (STC) is a number value quantifying the ability of a material to resist the transmission of sound. For example, 25 STC would mean only normal speech can be understood through the system, while 50 STC would mean almost nothing could be heard.
MOUNTING/ANCHORING
CARVART offers several types of structural suspension assemblies and coordination services to advise on best practices for supporting the wall system.
WEIGHT & STRUCTURAL LOADS
Panels range in weight from 10lbs - 16lbs per square foot. Weight is dependent on panel type, glass type and specified acoustic insulation. Consult CARVART pre-construction team for project specific weights and loads.
COLORS
INSTALLATION
System is top-hung and requires trained industry professional to ensure installation meets quality and safety standards. Top supporting suspension structure provided by CARVART is pre-engineered and anchoring and connections to structure/substrate must be coordianted by structural engineer. All panels come pre-assembled. Top track and structure above system must be cut-to-size on site and assembled. CARVART offers on-site and remote training for all installers new to the product or requiring a refresher. Certain glass and hardware components/finishes are only available as “knock-down” products and require site-assembly. Consult a CARVART agent for information on available pre-assembled components.
DETAIL
CONFIGURATIONS
Infinite ways to move and park panels to close and open a space to desired specification.
