DOUBLE SLIDING GLASS DOORS
DOUBLE SLIDING GLASS DOORS
Carvart framed and frameless glass doors add a sophisticated aesthetic and functionality to any environment.
Options such as sliding glass doors, telescopic doors, and swing doors can create a minimalist look and feel previously unavailable in highly-functional egress applications.
Whether used as stand alone or incorporated into our partition systems, our glass doors will bring the unique touch to your project.
Additional options for visible or hidden tracks are available with many systems. With a myriad of hardware, frame and mounting options, carvart door systems use the mediums of glass and woods to beautifully integrate into any space.
Contact our team or your local representative to find out more about glassdoors, design tools, and price ranges.
INFORMATION
BRAND
Carvart
PRODUCT TYPE
Sliding Doors
GLASS PANELS RANGE
- Minimum : 29"
- Maximum : 48"
SURFACES
- Smooth Glass
- Etched Glass
GLASS TYPES
- Tempered Monolithic
- Tempered Laminated
COLLECTION
Double
PRODUCTION
Made in NewYork
GLASS FINISHES
Carvart laminated transparent glass design options available.
HARDWARE DIMENSIONS
- Vertical side rails: 1-3/4" deep x 1/8" wide.
- Horizontal side rails: 1-3/4" deep x 1/8" wide.
- Aluminum top track : 2-5/8" wide x 2" high nominal.
FUNCTION
Top-hung sliding double panel.
GLASS THICKNESS
Accommodates 1/4" nominal.
MOUNTING FASTENERS
- Carvart advisory and coordination available.
- Mounting fasteners and anchors to be supplied by others.
- Final anchoring decision is client-directed or based on client structural consultant.
FACILITY DESIGN APPLICATIONS
Space division between offices, conference rooms or flex-space, bathrooms.
DOWNLOAD
ā Data Sheet
HARDWARE WARRANTY
5 Years
ADD-ON DESIGN OPTIONS
-Various pull options. -Various plastic/brush connection details for increased privacy.
WEIGHT & STRUCTURAL LOADS
Consult local engineer for structural codes and requirements
- Refer to carvart for technical consultation.
- Top rails for individual panels rated up to 220 lbs.
- Linear per foot weights based on final glass type.
- Overall weights available upon request for client structural calculations.
DETAIL
SECTIONS
- Typical Horizontal Section
- Typical Vertical Section
OPTIONS: CONFIGURATIONS
- Concealed
- Side Mount
- Surface Mount
- Concealed Pocket
INSTALLATION
-Pre-assembled doors optimize installation and ensure high quality miters. -Requires trained and competent glazing or carpenter industry professionals. -Installation instructions, assistance and training available at time of order. -Limited components make for fast installation. Pre-cut top track speeds up install available.
-All hardware components, including doors, will be delivered knocked down and require assembly by a glazing industry professional. Certain glass and hardware finishes are available as pre-assembled products as called out in the glass and hardware finishes pages. Consult a CARVART agent for information on available pre-assembled components.
FINISHES
HARDWARE FINISHES
