Usg Ensemble® Acoustical Drywall Ceiling
Ensemble® Acoustical Drywall Ceiling
ENSEMBLE® ACOUSTICAL DRYWALL CEILING
The first integrated ceiling system offering ideal combination of seamless design and superior acoustics.
INFORMATION
BRAND
Usg
PRODUCT TYPE
Ceiling System
BACKER PANEL
1" USG Ensemble® High-NRC
EXCELLENT SOUND PERFORMANCE
- NRC 0.80 and CAC 40
- Acoustically transparent USG Ensemble®Spray-Applied Finish
- Perforated USG Sheetrock® Brand Panels to optimize performance
COLLECTION
Ensemble®
PRODUCTION
Made in United States
TECHNICAL DRAWING
CLEAN, ELEGANT AESTHETICS
-Monolithic appearance with fine finish in standard white and custom colors -High light reflective finish (LR-85) looks elegant and reduces fixture and energy use
FEATURES AND BENEFITS
-System installed on economical, suspended USG Drywall T-Bar grid. -Backed by USG's advanced design and engineering, certified installer and sales support network, and full system warranty.
TOTAL QUALITY ASSURANCE
- Integrates with lighting and HVAC fixtures.
- Easy maintenance - repairs like standard drywall.
- USG makes all components and offers system warranty.
- Available options: direct mount ceiling and wall systems.
COST
Up to 50 % lower installed cost versus acoustical plaster systems.
LOWER INSTALLATION COSTS
System is up to half the installed cost versus acoustical plaster systems
WEIGHT
3.2 lb/ft
FIRE CLASS
A
EASIER INSTALLATION
-Installs and finishes similar to standard drywall techniques -Support from network of USG Ensemble® certified installers
APPLICATIONS
- Atria
- Lobbies
-Concourses
- Museums
- Hospitality
- Restaurants
- Corporate interiors
- Performing arts spaces
- Board rooms/executive offices
- Classrooms/ higher education
FLAME SPREAD
25 or less
SMOKE DEVELOPED
50 or less
