PILKINGTON PYROSTOP DOOR PANEL
PILKINGTON PYROSTOP DOOR PANEL
Fire-rated, safety-rated transparent wall panel
Pilkington Pyrostop® is a fire-rated and impact safety-rated glazing material that blocks radiant heat, protecting people and valuables on the non-fire side of the glass where radiant heat transfer might be a concern. It is listed for use in doors, sidelites, transoms, borrowed lites and wall applications.
INFORMATION
BRAND
Fireglass
PRODUCT TYPE
Door Panel
STREAM TEST
Fire-rated for up to 120 minutes with required hose stream test
IMPACT SAFETY-RATED
Impact safety-rated - meets ANSI Z97.1 and CPSC 16 CFR1201 (Cat. I and II)
MATERIAL
Glass
TGP
Fits in most Fireframes® frame and door systems by TGP
AVAILABLE SIZES
Large sizes available
THERMAL SHOCK
Withstands thermal shock
COMPRISED LAYERS
Comprised of layers of Pilkington Optiwhite™ nearly colorless, wireless, low-iron float glass and clear intumescent interlayers
WARRANTY
5-year limited warranty
USE
For use in interior and exterior applications
ATTRIBUTES
- Fire-Rated
- Heat Barrier
- Hose Stream Tested
- Impacted Rated
- Positive Pressure Tested
- UL Classified & Labeled
DOWNLOADS
↓ Product Fact Sheet
↓ CSI Format Specs
↓ Care and Warranty
↓ Smartgard® Product Fact Sheet
↓ School Guard Glass® Product Fact Sheet
↓ Pilkington Pyrostop® BR Product Fact Sheet
AVAILABLE INSULATED UNITS
Available in insulated units with other glass products, including (but not limited to): Tinted; Art Glass; One-Way Mirror; Low-E; Reflective; Security Glass
VISION CONTROL®
Pilkington Pyrostop can be combined with Vision Control® integrated cord-free louvers in a UL-tested fire protection-rated glazing system available directly from Unicel Architectural
KEY FEATURES
-May be lightly sandblasted or etched on one side without affecting fire rating -Protection against radiant and conductive heat transfer -Multi-laminate, not a sensitive polymer gel unit -Most configurations are available with a translucent interlayer for added obscurity and privacy -Available with bullet resistance to UL Level III
LISTINGS/STANDARDS
Listed with Underwriters Laboratories, Inc.® File numbers are R13377 (45 minutes) and R38725 (60-120 minutes). Tests performed in accordance with:
DETAIL
INTERIOR
| FIRE RATING | 45 MIN. | 60 MIN. | 60 MIN. | 90 MIN. | 2 HR. |
|---|---|---|---|---|---|
| Manufacturer's Designation | 45-200 | 60-101 | 60-201 | 90-102 | 120-104 |
| Supply Form | Single Glazing | Single Glazing | Single Glazing | Single Glazing | I.G. Units |
| Nominal Thickness | 3/4" (19 mm) | 7/8" (23 mm) | 1-1/16" (27 mm) | 1-7/16" (37 mm) | 2-1/8" (54 mm) (with 8mm spacer, or 2-3/8" (60mm) with 14mm spacer) |
| Weight approx. (lb/ft2) | 9.22 | 10.86 | 12.90 | 17.61 | 21.71 |
| U-Value | .86 | .83 | .83 | .74 | .44 |
| Daylight Trans. approx. (%) | 86 | 87 | 86 | 84 | 74 |
| STC Rating approx | 40 | 41 | 44 | 45 | 46 |
| Max. Exposed Area (in2) Other than doors | 4.500 Max. exposed width: 95-1/4" Max. exposed height: 95-1/4" | 5.616 Max. exposed width: 96" Max. exposed height: 96" | 7.442 Max. exposed width: 96" Max. exposed height: 118-1/8" | 3.724 Max. exposed width: 96" Max. exposed height: 96" | 3.730 Max. exposed width: 111" Max. exposed height: 111" |
| Door | 3.724 Max. exposed width: 41-5/8" Max. exposed height: 89-3/4" | 4.222 Max. exposed width: 41-7/8" Max. exposed height: 100-13/16" | 4.222 Max. exposed width: 41-7/8" Max. exposed height: 100-13/16" | 4.222 Max. exposed width: 41-7/8" Max. exposed height: 100-13/16" | N/A |
EXTERIOR
| FIRE RATING | 45 MIN. | 60 MIN. | 90 MIN. - 2 HRS. |
|---|---|---|---|
| Manufacturer's Designation | 45-200 45-260 (IGU) 45-360* (IGU) | 60-201 60-261 (IGU) 60-361* (IGU) | 60-201 60-261 (IGU) 60-361* (IGU) |
| Supply Form | Single Glazing or I.G. Units | Single Glazing or I.G. Units | Single Glazing or I.G. Units |
| Nominal Thickness | 3/4" (19 mm) IGU - 1-5/16" (33 mm) | 1-1/16" (27 mm) IGU - 1-5/8" (41 mm) | 1-9/16" (40 mm) IGU - 2-3/8" (60mm) with 14 mm spacer or 2-1/8" (54 mm) with 8 mm spacer |
| Weight approx. (lb/ft2) | 9.22 12.29(IGU) | 12.90 15.98 (IGU) | 18.64 21.71 (IGU) |
| U-Value | 45-200/.86 45-260/.49 45-360/.37-.39 | 60-201/.83 60-261/.48 60-361/.37-.39 | 120-202/.72 120-262/.44 120-362/.35 |
| Daylight Trans. approx. (%) | 86 77 (IGU) | 86 77 (IGU) | 86 74 (IGU) |
| STC Rating approx | 40 | 44 | 46 |
| Max. Exposed Area (in2)Other than doors | 4.500 Max. exposed width: 95-1/4" Max. exposed height: 95-1/4" | 7.442 Max. exposed width: 96" Max. exposed height: 118-1/8" | 3.730 Max. exposed width: 111" Max. exposed height: 111" |
| Door | 3.724 Max. exposed width: 41-5/8" Max. exposed height: 89-3/4" | 4.222 Max. exposed width: 41-7/8" Max. exposed height: 100-13/16" | 4.222 Max. exposed width: 41-7/8" Max. exposed height: 100-13/16" |
