Insulfoam InsulFoam Single-Ply (SP) Insulation
INSULFOAM SINGLE-PLY (SP) INSULATION
INSULFOAM SINGLE-PLY (SP) INSULATION
Fire-Rated Single-Ply Roof Insulation with Factory Laminated Glass Facer
Ideal for low-slope roofing. InsulFoam SP is an engineered insulation consisting of a superior closed-cell, lightweight and resilient expanded polystyrene (EPS) with a durable and stable, factory-laminated coated glass facer.
INFORMATION
WATER RESISTANCE
InsulFoam SP does not readily absorb moisture from the environment.
BRAND
Insulfoam
PRODUCT TYPE
Insulation Material & Accessories
ENVIRONMENTALLY FRIEND
It does not contain any ozone- depleting blowing agents, may contain recycled material, and is 100% recyclable if ever removed or replaced.
ENVIRONMENTALLY FRIEND
It does not contain any ozone- depleting blowing agents, may contain recycled material, and is 100% recyclable if ever removed or replaced
PROVEN PERFORMANCE
EPS has been manufactured using the same chemistry since the mid-1950s, providing proven performance
DETAIL
InsulFoam SP is available in a nominal density of 1lb/ft3 or 1.25lb/ ft3 , and meets or exceeds the requirements of ASTM C578, Standard Specification for Rigid, Cellular Polystyrene Thermal Insulation. In addition, InsulFoam SP offers a long-term, stable R-value and has excellent dimensional stability, compressive strength and water resistance properties.
LABOR SAVINGS
With a factory-laminated facer, InsulFoam SP saves labor time and reduces overall project costs, when incorporated into a roofing system that would otherwise require a slip sheet.
SIZES
InsulFoam SP is available in several standard thicknesses. Non- standard sizes may also be ordered; InsulRoof SP can be made up to a thickness of 6” (R-26), with a minimum thickness of 2” for 1 lb/ft 3 insulation and 1.5” for 1.25 lb/ft 3 insulation.
STABLE R-VALUE
The product’s thermal properties will remain stable over its entire service life. There is no thermal drift, so the product is eligible for an Insulfoam 20-year thermal performance warranty.
USES
InsulFoam SP is specifically designed for low-sloped roof applications that employ mechanically fastened or ballasted TPO, PVC and EPDM, as well as low-sloped built-up, modified bitumen and fully adhered single-ply roofs that incorporate cover boards or slip sheets. InsulRoof is also designed for use in fully-adhered fleeceback systems with compatable adhesives. Please consult local building codes and membrane manufacturers for system requirements.
COLLECTION
Single-Ply
DOWNLOAD
↓ Data Sheet
