Tegola Canadese Top Shingle Rectangular Roof Tiles
TOP SHINGLE RECTANGULAR ROOF TILES
TOP SHINGLE RECTANGULAR ROOF TILES
Simplicity is synonymous with style if you talk about Premium Rectangular. The historic rectangular shaped bituminous shingles continue to be current.
FEATURES
EXCLUSIVE DESIGN
Exclusive DESIGN for any roof and context, thanks to the wide range of models and colors
WATERPROOFING
Waterproofing to ensure your roof quality and durability over time
LIGHTNESS
Lightness above your head to guarantee maximum safety, even in the event of a seismic event
RESISTANCE
Resistance to any extreme conditions, to hailstorm, to strong winds
SIMPLICITY
Simplicity they adapt to any shape and slope of the roof, easy to transport and apply… even on the construction site
INFORMATION
BRAND
Tegola Canadese
REFERENCE STANDARD
EAD 220020-00-0402
BITUMEN PER SINGLE LAYER
>1000 g/m²
TILES PER PACKAGE
24
SURFACE PER PARCEL
3.50 (m2)
SET OF THE FLAPS
Self-adhesive Pads
WATER ABSORPTION
<1 %/EN 544
WEIGHT
9.40 kg
SURFACE COATING
70 micron copper
M²/BUNDLE
2.32
M²/PALLET
185.60
HEIGHT OF SLITS
>143
THICKNESS
3
DOWNLOADS
↓ Data sheet
↓ Installation
IMPORTANT
This Product Does Not Contain Asbestos And Tar
DIMENSIONS
1100x34 cm
TENSILE STRENGTH MD/CMD
N/50mm/>600 / >400
RESISTANCE TO TEARING
>100/EN 12310-1
RESISTANCE TO UV RADIATION
Pass/EN 1297
STORAGE
Store pallets in closed warehouses, away from heat sources and direct sunlight. Store in the original packaging. Do not stack pallets.
RESISTANCE TO BLISTERING
Pass/EN 544
FLOW RESISTANCE, AT 90°C
<1mm/EN 1110
APPLICATION
Application on pitched roofs, with a slope between 5° and 85°. Installation temperature above +5°C. Always check the adhesion of the pads or of the shingle at the end of the installation.
GRANULES ADHESION
<1,2 -g/EN 12039
EXTERNAL FIRE RESISTANCE
Broof (t1)/EN 13501-5 / EN 1187
SAFETY
The material is free of asbestos, tar compounds and other dangerous substances.
OTHER INFORMATION
The characteristics expressed refer to the standard production. Tegola Canadese reserves the right to update the technical data sheets without notice. Further information on installation available
REACTION TO FIRE
E/EN 13501-1 / prEN ISO 11925-2
TYPE
Polyethylene Film
COLORS
