RABEL 60 SUPER THERMAL WINDOWS & SLIDING DOORS
RABEL 60 SUPER THERMAL WINDOWS & SLIDING DOORS
Heavy Duty Sliding System Up To 200kg
Although the Rabel 60 super thermal represents the entry edition in the Rabel 60, 600, 6000 Super thermal family of sliders, it still outperforms the majority of sliders in the market.
Having a maximum weight capability of 200 Kg per sash using synthetic rollers / 400Kg per sash using Stainless Steel rollers, its relatively flat bottom track and a max height of 3.0 meters, can be the ideal choice to satisfy the needs of the most demanding projects.
It is equipped with a custom made multipoint locking system that fulfils the highest standards for burglary resistance and is powered by a selection of design handles or recessed latches.
INFORRMATION
BRAND
Rabel
PRODUCT TYPE
Windows & Sliding Doors
THERMAL BREAK WIDTH
24 / 64 mm
DESIGN
They also have the capability to fabricate a 90 degrees inner and also outer corner, making it thus possible to design and fabricate continuous doors in a "Z" formation.
MAX. WEIGHT PER SASH
400* Kg
CENTER MULLION WIDTH
80 mm
FRAME VISIBLE WIDTH
80 mm
FRAME HEIGHT
49 mm
SASH DEPTH
60 mm
SASH HEIGHT
80 mm
FABRICATION
All sliders in the Rabel 60, 600, 6000 Super thermal family have the capability to fabricate a 90 degrees corner without fixed mullion. The fabrication has been optimised so that the corner mullion is not visible when looking at the inner corner thus providing consistent aesthetics with the remaining fabrication.
SEALING TYPE
Brush with Clot
SASH VISIBLE WIDTH
60 mm
MAXIMUM LOCKING POINTS
4/5
DRAINAGE SYSTEM
It is available in all common typologies as well as 90 degrees corners without a fixed mullion. It comes with a sophisticated high performance water drainage system that is hidden below the frame.
MEASURING
Having a profile 60mm in width it can accommodate very thick acoustical double glazing panes for soundproofing as well as triple glazing panes for enhanced thermal performance. All of these features and performance characteristcs come with a very small sash width and central mullion measuring 80mm.
GLAZING WIDTH POSSIBILITIES
34 / 40 mm
PERFORMANCES
Fabrication Thermal Transmittance EN ISO 10077-2 (Uw) : ≥1.3 W/(m2K)
