Kaldewei Cayono Duo Bathtub
CAYONO DUO BATHTUB
CAYONO DUO BATHTUB
Designed by Kaldewei Desig
Modern rectangular bathtub with straight lines and small radius. Perfect match for the CAYONO model range
INFORMATION
BRAND
Kaldewei
PRODUCTION
Made in UK
PRODUCT TYPE
Batthtub
COLLECTION
Cayono
DETAIL
-Two gently sloping backrests and the central waste and overflow fitting ensure relaxed bathing with a partner -Spacious interior provides amble room for a relaxing bath -Made of KALDEWEI steel enamel
NET WEIGHT
48 kg
MODEL
724
WATER VOLUME
130 L
EXTERNAL RADIUS
R1 : 8 mm
DEPTH INSIDE
C1 : 400 mm
DEPTH INCL. WASTE HOLE
C2 : 410 mm
HEIGHT OF RIM
C4 : 32 mm
WIDTH OF RIM
E1;E2 : 80; 63 mm
DIMENSIONS
- External Width B1 : 750 mm
- External Length A1 : 1700 mm
- Internal Width B6 (Top) : 624 mm
- Internal Length A6 (Top) : 1540 mm
- Internal Length A7 (Bottom) : 1220 mm
- Internal Length B11 (Bottom) : 410 mm
DISTANCE BETWEEN THE FEET
H4 : 675 mm
DISTANCE FOOT END OF BATH EDGE TO CENTRE OF FOOT
H2 : 513 mm
HEIGHT WITH FEET
C3 : 545 - 580 mm
WIDTH OF FEET MAX.
H6 : 475 mm
FULL ANTI-SLIP
855 x 315 mm
ANTI-SLIP
Ø 289 mm
DOWNLOADS
↓ Technical Sheet
↓ Planning Data
DIAMETER OF OVERFLOW & WASTE HOLE
F8 & F9 : Ø 52 mm & Ø 52 mm
APPLICATIONS
Bathrooms
DESIGNER
Sottsass Associati
DISTANCE TOP EDGE TO CENTRE OF OVERFL OW HOLE
F 1 : 70 mm
DISTANCE BATH EDGE TO CENTRE OF OVERFL OW HOLE
F 2 : 850
TECHNICAL DRAWING
THE EXCELLENT BATHTUB
The Cayono Duo Is The First Kaldewei Duo Bathtub In The Advantage Segment And Offers An Attractive Solution For Relaxed Bathing For Two. The Cayono Duo Impresses With A Lot Of Space, Comfort And A Spacious Interior. Cayono Bathtubs, Together With Cayonoplan Showers And Cayono Washbasins, Set The New Standard In Family Bathrooms.
DETAIL
STEEL ENAMEL
KALDEWEI steel enamel is extremely resistant, durable and sustainable. Robust steel and fine glass, two authentic, natural materials form an inseparable bond.
DESIGN
An exquisite, sustainable material like kaldewei steel enamel deserves a timeless design. Our bathroom objects will touch and delight you each day. In addition to our own creations, we rely on the expertise of renowned designers.
SUSTAINABILITY
We live and produce sustainability. Steel enamel is made from natural raw materials and is 100 percent recyclable after a long life cycle. That makes kaldewei steel enamel the most sustainable material in your bathroom!
