Isometal Alfa 1 Roofing Sheets
ALFA 1 ROOFING SHEETS
ALFA 1 ROOFING SHEETS
INFORMATION
THICKNESSES (S)
25 -30 - 35 - 40 - 50 - 60 - 80 - 100 - 120 - 140 - 150 - 160 - 180 - 200 mm panels of non standard thicknesses can be supplied upon request previous agreement on minimum quantities (max. mm 200).
BRAND
Isometal
PRODUCT TYPE
Roofing Sheets
MATERIAL
- Steel
- Alluminium
- Copper
EPD CERTIFICATION (CAM)
-CAM available only in PIR version. -For more information on CAM certification, contact the technical / commercial department.
PROTECTIVE TREATMENTS FOR EXTERNAL SUPPORT AVAILABLE
On request for external polyester coating, atoxic prepainted for food contact, silicone polyester, PVDF, thermoplastic Class A application of PVC plastic films or other films
SUPPORTS
Galvanized steel, galvanized prepainted or plastified steel; stainless steel; natural or prepainted aluminium; copper (coram).
DIMENSIONS
-Width : 1000 mm
-Length upon request from continuous production process.
COLLECTION
Alfa 1
PRODUCTION
Made In Italy
INSULATION THROUGH CONTINUOUS FOAMING PROCESS
Polyurethane resins (PUR) and (not standard) polyisocianurate foams (PIR), density 39 ±2 Kg/m³ Declared value of thermal transmittance for a panel after 25 years of its installation, (Appendix C - EN 13165) Initial value of thermal conductivity: λ = 0.020 W/(mK)
INSIGHTS PIR FOAM
On request is available in PIR foam version (polyisocyanurate), a particular polymeric structure that guarantees excellent characteristics of fire behavior. The entire range of ISOLPACK panels has been certified in Class B-s2, d0 at CSTB (France) and at KIT (Germany) in compliance with UNI EN 13823 (SBI) * where, "B" expresses the quantity of heat produced during the first 600 seconds of the test <7.5 MJ (best value obtainable for foamed products); "S2" represents a very low development of the fumes and "d0" indicates the absolute absence of drops and/or inflamed particles. In last years, the SBI test has become a standard requirement in Europe for fire behavior of building materials. The new European standard for sandwich panels - UNI EN 14509 - uses the SBI system for fire classification purposes. ISOLPACK is the only one in Italy to design light, highly insulating applications with unequaled fire reaction requirements. In many cases it can replace the rock wool panel considering its fire reaction characteristics combined with the very high thermal insulation power.
O UNIFORMEMENTE DISTRIBUITO
COEFFICIENT OF HEAT LOSS
| THICKNESS | TRASMITTANCE EN UNI 14509 | (8 DAYS)TRASMITTANCE (8 GG / 8 DAYS) |
|---|---|---|
| (mm) | U = W/m2 K | U = W/m2 K |
| 25 | 0,82 | 0,75 |
| 30 | 0,70 | 0,64 |
| 35 | 0,61 | 0,55 |
| 40 | 0,53 | 0,49 |
| 50 | 0,43 | 0,39 |
| 60 | 0,36 | 0,33 |
| 80 | 0,28 | 0,25 |
| 100 | 0,22 | 0,20 |
| 120 | 0,18 | 0,16 |
| 140 | 0,16 | 0,14 |
| 150 | 0,15 | 0,13 |
| 160 | 0,14 | 0,12 |
| 180 | 0,12 | 0,11 |
| 200 | 0,11 | 0,10 |
