Isolgomma Uproll Insulation Accessories
UPROLL INSULATION ACCESSORIES
UPROLL INSULATION ACCESSORIES
Impact noise acoustic insulation with high acoustic performance and mechanical stability, made in rolls with sbr rubber granules
INFORMATION
PROCESS
9 mm acoustic insulation rolls, made of SBR (Stirene Butadiene Rubber) fibres and granules rubber, compacted using a latex binder in a hot process.
BRAND
Isolgomma
COLLECTION
Uproll
PRODUCT TYPE
Insulation Accessories
PRODUCTION
Made in Italy
APPLICATION
Under screed
TYPE
Impact insulation
DETAIL
-Resistant to dampness -Quick, easy and precise laying of the product -High sound insulation performance in reduced thickness
DOWNLOADS
↓ Technical data
↓ Depliant Under Screed
↓ Declaration of performance
↓ Cat. Solutions for acoustic insulation timber structures
RECYCLED CONTENT
90%.
USE
Floor
IMPACT SOUND LEVEL ATTENUATION ΔLW (DB)
24
THICKNESS
9 mm
INSTALLATION
Dry
SOUND PRESSURE LEVEL
Dynamic stiffness s‘ 11 and impact sound pressure level attenuation 24 dB.
THERMAL CONDUCTIVITY
Reaction to fire E, thermal conductivity coefficient 0,096 W/m K.
ANTI-STRETCH
A grey synthetic non woven anti-stretch backing is applied on one side.
APPLICATIONS
-Heated floors -Floor slabs with floating floor with reduced thickness
MASS SURFACE
3.10 kg/m²
UNDER APPLICATION
CLS floor
DYNAMIC STIFFNESS S' (DB)
11
SUPERFICIAL WEIGHT
3.10 kg/m²
DIMENSIONS
The dimensions of the roll are: 500 cm lenght, 104 cm width including 4 cm adhesive side border for rolls overlapping during installation.
