ONDULINE DURO SX 35
ONDULINE DURO SX 35 is a premium quality bituminous corrugated roof sheet with industrial aesthetics for a professional finish.
The profile of the DURO SX 35 roof sheet is made up of a combination of flat and corrugated sections for a modern look similar to a traditional metal boxed profile but with the additional Onduline benefits.
ONDULINE DURO SX 35 is the highest quality sheet in the Onduline range, with a profile thickness of 3.5 mm and a complete waterproofing guarantee of up to 20-years.
The thickness and quality of the roof sheet provide great durability making it ideal for commercial and industrial projects.
INFORMATION
BRAND
Onduline
LENGTH
2000 cm
PRODUCT TYPE
Roof Sheet
WIDTH
820 cm
WARRANTY
20 years
COLOURFUL RANGE
Available in a range of popular painted and intense colours for enhanced durability and to suit different applications: forest green, anthracite grey, classic red and intense red which is glossier in appearance.
SURFACE
1.34 m²
THICKNESS
3.5 mm
WEIGHT OF A PANEL
6 kg
WAVE HEIGHT
38 mm
WEIGHT PER M²
3.66 kg/m²
MINIMUM PITCH
5°
MAX OVERHANG
3.5 cm
| SLOPE IN ° | PURLIN SPACING |
|---|---|
| > 15 ° | 46 cm |
| 10° - 15° | 37 cm |
| 5° - 10° | Full Deck (OSB, Plywood...) |
PRODUCT BENEFITS
- Easy to install
-Lightweight
- Trapezoidal profile
- Guarantee: 20 years guarantee
- Eco-friendly: made from recycled fibres
-Enhanced acoustics: noise dampening material especially when compared with metal sheets
HORIZONTAL OVERLAP
15 Cm
SIDE OVERLAP
9.5 cm
COLORS
