Sunroom S.75 Tt Folding Door
S.75 TT FOLDING DOOR
S.75 TT FOLDING DOOR
There are truly an infinite number of opportunities to be had from a folding door! Elegant and original, it becomes a true furnishing accessory that can satisfy any design need: the S.75 TT folding door can be completely packed to overcome the boundary between indoors and outdoors and offer you maximum construction freedom and creation of spaces.
Its panels are always built to measure, while the upper and bottom tracks and side jambs create a closed frame with double gaskets that act in compression for excellent performance.
The special system of the S. 75 TT folding door is also ideal for climate zones where resistance to weather, sealing, and thermal and acoustic insulation are of major importance. The thermal break is obtained through 28 mm polyamide Barss to promote excellent living comfort and greater energy efficiency.
The specifically designed accessories combine the need to support large weights with an innovative aesthetic taste. This particularly applies to the anodised aluminium and stainless steel rollers and hinges, as well as the square and minimal handles.
Pack gathering is easy, quick, and quiet. It can be to either left or right or, for larger glazed units, even divided on both sides. With the S. 75 TT folding door you can obtain well-being in the environment that you always dreamed of, where temperature, brightness, and comfort become synonymous with “feeling good” at home!
INFORMATION
BRAND
Sunroom
PRODUCT TYPE
Folding Doors
CODE
S.75 TT
PRODUCTION
Made in Italy
PRODUCT PLUS
- Thermal break
- Energy saving
- Patented Design
DIMENSIONS
- Maximum Panel Width : 1000 mm
- Maximum Panel Height : 3000 mm
MAXIMUM PANEL WEIGHT
100 kg
WEIGHT OF GLAZED UNIT
8-12 kg/m2 excluding glazing
PLUS OPTION WITH INSULATION
Upon Request
THERMAL INSULATED PROFILES
Yes
ADJUSTMENTS
Yes
SLIDING
Bottom
HEIGHT OF BOTTOM TRACK
- Standard – 66 mm
- Upon request - lowered 20 mm
THERMAL BREAK
The thermal break is obtained with 28mm polyamide bars. The upper and bottom tracks and the side jambs create a closed frame and, together with the panels, have double gaskets that act on compression for excellent thermal and sound insulation.
SLIDING ACCESSORIES
Stainless Steel
HINGED PANEL LOCK
Multipoint
FINISHES
DOWNLOAD
↓ Data Sheet
TOP TRACK PROFILE
75 mm
PATENTED DESIGN
The linear and reduced forms are characterized by the exclusive SUNROOM style and offer a pleasant and original appearance.
STEEL ACCESSORIES
The carefully researched and tested materials, such as the stainless steel accessories, ensure the best functionality, reliability, and durability
FEATURES
- Right / left packing : Yes
- Glazing : 31/33 mm, 44/47 mm
- Inward / outward opening : Yes
- Closures : Top, Bottom And Frame
- Sliding corner type : Upon Request
- Gathered glazed unit dimensions : 12%
- Thermal transmittance 4 panel glazed unit – 4000 x 2500 mm glass ug=0.6 w/m2 k, psi=0.05 w/mk : UW = 1.15 W/m2 k
- Opening From Outside With A Key : Upon Request
- Air permeability certification en 1026 – en 12207 : Class 4
- Wind resistance certification en 12211 – en 12210 : Class b5
- Water tightness certification en 1027 – en 12208 : Class 8a
- Thermal transmittance (plus option) 4 panel glazed unit – 4000 x 2500 mmglass ug=0.6 w/m2 k, psi=0.05 w/mk : UW = 1.00 W/m2 k
