LATERLITE EXPANDED CLAY: LIGHTWEIGHT INSULATING STRONG AGGREGATE
Laterlite Expanded Clay is a lightweight aggregate (LWA), with insulating characteristics made by expanding special natural clays at high temperature (1200°C).
Laterlite Expanded Clay is manufactured in different types and sizes, in granular or crushed form, standard (lighter and insulating applications) or structural (high mechanical strength applications).
Laterlite Expanded Clay aggregates uniquely combine low density and thermal insulation with high mechanical strength, which is achieved thanks to the, clinkerised rigid outer shell surrounding the internal cellular structure of the granules.
These properties make Laterlite Expanded Clay extremely versatile, finding multiple uses in construction and civil engineering, loose on his own or mixed with binders (cements, lime, resins…), for insulation, drainage, or reduction of dead loads.
These characteristics are also highly valued when used in the production of blocks, mortars, screeds, concretes, and refractory products, in a wide range of densities and strengths.
CHARACTERISTICS AND ADVANTAGES
LIGHTWEIGHT, INSULATING, STRONG AGGREGATE
Its porous internal structure means Laterlite Expanded Clay is lightweight (from approx. 320 kg/m³), thermally insulating (thermal conductivity lambda l from 0.09 W/mK), and sound-absorbent. The ceramic “clinkered” outer shell surrounding the expanded clay granules makes them very hard and resistant to compression (up to 12 N/mm).
NON-COMBUSTIBLE AND FIRE-RESISTANT
Laterlite Expanded Clay is composed by 100% mineral non-combustible aggregates (Euroclass fire rating – A1), does not contain organic compounds or derivatives, is fire-resistant and safe, including in the presence of fire. It is commonly used in refractory applications.
EXTREMELY STABLE AND DURABLE
-Laterlite Expanded Clay will not rot, cannot be attacked by parasites (fungus, rodents, insects, etc.), is resistant to acids, bases, solvents, and freeze-thaw cycles. -Lightweight Expanded Clay aggregates are dimensionally stable and non-deformable and retains their properties unaltered over time. -They are one of the most durable of all building materials: for all practical purposes, these aggregates will last forever.
A NATURAL MATERIAL FOR SUSTAINABLE CONSTRUCTION
The natural raw materials used in Laterlite Expanded Clay, its manufacturing process that respects the environment, and the total absence of harmful emissions (even in the presence of fire), make it ideal for sustainable construction as certified by ANAB-ICEA, the Italian Accreditation Institute.
HIGH DRAINAGE CAPACITY
Because of its granular nature, which consists of a dense network of intergranular voids with high drainage capacity, Laterlite Expanded Clay aggregates can be used to create lightweight drainage layers of high strength.
VERSATILITY
-Laterlite Expanded Clay is used extensively in construction, both loose on its own or mixed with binders (cement, lime, resins, etc.). -It is widely used as a component of concretes, in blocks and precast elements, for agricultural and horticultural applications, and in geotechnical engineering and infrastructure works.
CE-MARKED
Laterlite Expanded Clay is manufactured and tested in accordance with international reference standards and is CE-marked to denote conformity to EN 13055-1, EN 14063-1, and EN 13055-2.
information
PACKAGE
Bags each of 50 litres on wooden pallets, 50 bags/pallet – 2,5 m3/pallet.
BRAND
Laterlite
PRODUCT TYPE
Laterlite Expanded Clay
DOWNLOADS
↓ Data sheet
↓ Catalogue
FIELDS OF USE
-Lightweight and insulating backfill. -Lightweight and insulating floor substrates. -Flat and sloping roofs (slopes, screeds, insulation, etc.) -Drainage -Lightweight embankments and other geotechnical and civil engineering applications -Landscaping and green roofs -Structural and non-structural lightweight concretes -Prefabricated concrete elements. -Bituminous conglomerates for road surfaces -Refractory insulation, concretes and mortars -Road de-icing dispersions (environmentally friendly alternative to salting) -Water treatment
CONCRETE ELEMENTS
Prefabricated concrete elements.
CONCRETE
Structural and non-structural lightweight concretes
APPLICATIONS
Laterlite Expanded Clay is an extremely versatile material that can be used both loose on his own and bonded with different types of binders when needed.
CONSIGNMENT
-In bags on pallets, in big bags, or in bulk, or even in silo trucks equipped for on-site pumping (available in specific areas only), Laterlite lightweight expanded clay aggregates can be delivered in the most suitable way for the needs of the site or the user. -More information can be found on the delivery forms page and in the product documentation. -Granular Laterlite Expanded Clay is supplied in 50 litre polyethylene bags (20 bags/m3), palletised in the following quantities: –2-3 : 60 bags per pallet (3.0 m3) – 3-8 : 75 bags per pallet (3,75 m3) – 8-20 : 75 bags per pallet (3,75 m3) 3-8 and 8-20 grain sizes are also available on request in pallets each holding 35 bags.
