LITOKOL X11
LITOKOL X11
Improved cementitious adhesive with no vertical slip and extended open time for the installation of ceramic and porcelain tiles and natural stones on interior and exterior walls and floors. Suitable for overlaying and underfloor heating. Product with very low volatile organic compound emission rate.
INFORMATION
RAND
Litokol
COLLECTION
LITOKOL X11
MATERIALS
-Ceramic and porcelain tiles -Double fired -Single fired -Terracotta - Clinker -Marble – Granite –Stone -Natural stones -Ceramic and vitreous mosaics Porcelain stoneware
ADVANTAGES / FEATURES
-Product exhibiths Very low volatile organic compound (VOC). Complies with the most stringent Global Air Quality Regulations. -Maintains excellent pot life over time, without any bothersome thickening -Allows the installation of ceramic, porcelain and mosaic wall coverings without the need for plastic spacers -Suitable for installation on heating screeds -Suitable for overlaying on existing flooring
PACKAGING
44lb (20 kg) bags - 2,645.5lb (1,200 kg) standard pallet of 60 bags
INTENDED USES
- Interiors and exteriors
- Floors and walls
- Underfloor heating
- Facades
- Overlaying Terraces and balconies
- Residential, public, commercial building
SUITABLE SUBSTRATES
-Cement screeds -Self-levelers -Skim coats -Existing tiles -Waterproofing systems -Underfloor heating systems -Concrete -Gypsum -Fiber cement slabs -Gypsum and anhydrite -Aerated concrete -Plasters
CERTIFICATIONS & SUMMARY
KEY
- After treatment with Primer C or Primer X94. Maximum humidity = 0.5%.
- Curing time: minimum 6 months.
- After cleaning and degreasing with Litoscrub EVO.
- After treatment with the adhesion promoter Prepara Fondo EVO.
- After treatment with Primer C or Primer X94 for non-waterproof gypsum.
- After treatment with Primer X94.
PLANNING
SUBSTRATES
Before installation, check that substrates are clean, free of loose fragments, properly dried and cured, flat and level, and that mechanical strength requirements based on the intended use have been met.
INSTALLATION PLANNING
The only way to guarantee the long-lasting performance of ceramic and porcelain tile installations is to properly plan the process. It is therefore advisable to consult the national regulations in force in each country, for example standard UNI 11493 in Italy, which provides all necessary instructions regarding the choice of materials, correct planning, use and installation, so as to ensure all quality, performance and durability standards are safely met.
WORKSITE CONDITIONS
Check the suitability of the temperature, humidity, light conditions etc. at the time of the product’s application.
BACK-BUTTERING
For exterior installations, large tiles, floors with intense or heavy traffic, vibrating supports and situations exposed to high temperature fluctuations, the adhesive mortar must be applied to both the substrate and the back of the tiles so as to obtain a solid bed of adhesive without any air bubbles.
MATERIALS
Check that all materials used for tiling (ceramic materials, leveling systems, adhesives, grouts, waterproofing products, etc.) are suitable for the intended use and have been correctly stored.
EXPANSION JOINTS
Check that the perimeter, expansion, divider and structural elastic joints have been correctly designed and prepared. Divider joints are normally needed for 20/25 m2 (21.9/27.3yd2 ) indoor sections, and 9-15m2 (9.84/16.4yd2 ) outdoor sections. For exteriors, make sure joints are properly waterproofed and sealed.
JOINTS
In any type of ceramic and porcelain tiling, suitably sized joints must be created based on the following parameters :
- Type, format and size tolerance of tiles
- Thermal expansion coefficients of tiling materials
- Mechanical properties of installation materials
- Position and trajectory of joints
- Mechanical features of substrate
- Intended use and operating conditions
