Aritco Aritco Publiclift Cabin lift
ARITCO PUBLICLIFT CABIN LIFT
ARITCO PUBLICLIFT CABIN LIFT
Our cabin elevator for public & commercial building. The elevator is designed with simplicity in mind.
features
OTHER DETAILS
-Design, sizes and options tailored for public environments -Minimum interventions in the building -One of the lowest maintenance and operating costs on the market -Cabin control: Automatic ”one-touch” -Eurocode 3 compliant
OUR CABIN ELEVATOR FOR PUBLIC & COMMERCIAL BUILDINGS
The elevator is designed with simplicity in mind. It looks, feels, performs, and operates like a conventional passenger elevator. With no machine room or deep pit required, it offers complete freedom in design and simple usability, providing total safety in use.The energy-efficient traction drive and fully automatic telescopic doors make it a versatile, cost-effective passenger lifting solution
information
CUSTOMIZATION
Customization possibilities by the millimeter. With or without self-supporting shaft.
BRAND
Aritco
TRAVEL HEIGHT
250-14 600mm
TECHNICAL COMPLIANCE
European Machine directive 2006/42/EC European standard EN 81-70
NUMBER OF FLOORS
2-5 floors
TRAVEL HEIGHT
250-14 600mm
DRIVE SYSTEM
Double belt traction drive system 3kW motor
TOP HEIGHT
Min. 2600mm (Optional 2700-2800 mm)
INSTALLATION
-Recessed installation with self-supporting shaft 140mm
-Recessed installation in a wall shaft 120mm -Installed directly on floor with ramp
POWER SUPPLY
230 V 1-phase
EMERGENCY LOWERING
Battery-powered
WARRANTY
Aritco PublicLift Cabin comes with a 5 year warranty.
The belts have a 10 year warranty.
DOWNLOADS
↓ Brouchers
RATED SPEED
Max 0.15 m/s
DIMENSIONS
- Persons: 5 pers
- Rated load :400 kg
- Platform sizes: 1000 x 1240 mm, 1140 x 1400 mm
- Wheelchair: Lone user or type A , A or B with attendant
colour & MATERIALs
SHAFT COLOR
-Grey RAL 7040 (standard) -Optional RAL
SHAFT MATERIAL
-Clear glass -Tinted glass
CABIN MATERIAL
FLOOR MATERIAL
