Scolaro Napoli Standard Timber Beam
NAPOLI STANDARD TIMBER BEAM
NAPOLI STANDARD TIMBER BEAM
Combination of an aluminium frame colour anthracite grey and the simplicity of its lines. Perfect union between resistance and elegance.
Parasol robust and practical with central aluminum pole painted with epoxy powder of gray anthracite color. Particularly appreciated since last years by the robustness and compatibility with any environment and use. Pole of 50 mm ø..
INFORMATION
BRAND
Scolaro
PRODUCT TYPE
Timber Beam
FABRIC
All Acrylic Dralon 350gr/m2 waterproof Teflon and anti-mould treated. With wind cap. Solution dyed. 5 years warranty
TELAIO
Acrilico Dralon 350gr/m2 impermeabilizzato e trattato antimuffa garantito Teflon. Con camino antivento. Tinto massa. 5 anni di garanzia.
PRODUCTION
Made in Italy
COLLECTION
Napoli
DOWNLOADS
↓ Technical Sheet
USE
Suitable for all environments.
COLOUR RANGE
-A1S -A1N -T2S - T3S -T6N
-T7N -S1N - T8N -T9N
OPTIONAL
- Cover Bag
- Brass Finishing
- With Base Support
- Cement Slabs & Raingutter Set
FRAME
Strong aluminum frame with elegant oval outlines. Epoxy coated color anthracite grey. Accessories in stainless steel and strong nylon components. Pole diameter 50mm. Strong interchangeable ribs, section 18x30mm. Double pulley for an easy opening.
TELAIO
Robusto in alluminio con eleganti profili ovali. Verniciato a polveri colore grigio antracite. Accessori zincati antiruggine e componenti in nylon resistenti. Palo diametro 50 mm. Stecche robuste intercambiabili con sezione 18x30 mm. Apertura e chiusura con doppia carrucola.
REVOLVING BASE
360°
SCREWS
Screws in Stainless steel and nickel plated brass
BASE
- BC55MA4
- BC80MA4
- BTT55+BTC
- BUD8080
- BF6565D - BF6565Z
- BF6666D - BF6666Z
FINISHING
-Wind CaP -Wind stop
-With winding mechanism
-With base-support -Double pulley -Inclination up to 20° &
up to 60° -Retractile system
-Telescopic system -Valance
-Gas spring opening
TECHNICAL DRAWINGS
CHARACTERISTICS
| MEASURES | CODE | WEIGHT KG | VOLUME M3 | POLE MM | SUPPORT SECTION | FINISHING FRAME | RIBS | COMPONENTS | RIBS SECTION |
|---|---|---|---|---|---|---|---|---|---|
| 3.0x3.0 | C3040 NAS | 18 | 0.12 | 50 | - | ALUDARKCOL | 8 | ALUDARK | 18x30 |
| 3.0x3.0 | C3030 NAS | 15 | 0.11 | 50 | - | ALUDARKCOL | 8 | ALUDARK | 18x30 |
| 3.5 | C3500 NAS | 15 | 0.10 | 50 | - | ALUDARKCOL | 8 | ALUDARK | 18x30 |
