Daldoss Easy Go Lift
EASY GO LIFT
EASY GO LIFT
The Compact Lift
Electric or hydraulic lift for residential and commercial buildings also with reduced pit and headroom.
INFORMATION
BRAND
Daldoss
PRODUCT TYPE
Lift
PRODUCTION
Made in Italy
COLLECTION
Easygo
INSTALLATION
Wall mounted or structure supported frame (optional).
DETAIL
The innovative passengers lift that offers the fast, safe and efficient solution. Particularly suitable residential buildings and commercial activities where a high performance lift is required.
RATED LOAD
From 320 to 1000 kg
PASSENGERS
4-6-8-10-13
MINIMUM PIT
350 mm
MINIMUM HEADROOM
2800 mm
OPERATION
Collective/Selective up and down.
STOP
Up to 16 m (depending on models and type of traction).
TRAVEL
Up to 45 m (depending on models and type of traction).
SPEED
Max. 1.6 m/s.
POWER SUPPLY
220-400 V 3 phases 50/60 Hz
VERSIONS
- GO-e electric MRL solution with gearless technology.
- GO-h hydraulic solution with reduced and optimised shaft spaces.
RANGE OPTIONS AND CUSTOMIZATION
EasyGO is available in a wide range of models and finishes; the elegant car i nterior fi nishes and good illumination makes travelling in the lift a pleasure.
RATED POWER
Min. 2 kW (depending on models and type of traction).
SAFETY FEATURES
All the safety components as required by the European Standard EN 81 are built into standard models. Particular attention is paid to the requirements of both people with impaired mobility and elderly:
- Device to prevent overloading.
- Emergency light in case of power failure.
- Emergency Autocall Communicator for direct contact between the lift car and a service centre.
- Emergency Rescue Device for returning the lift to the bottom floor with “door opening” in case of a power failure.
