MANGUSTA LIFT
MANGUSTA LIFT
The energy-saving lifting platform
Miniwatt® is an Electric Platform Lift without cabin walls but which has a loading platform with stainless steel sensitive protective edge.
The mechanical parts are completely hidden by a protective metal panel available in RAL colours or stainless steel finish.
The top floor landing can be fitted with a gate rather than a classic door. The perfect solution for single-family homes and businesses, plus, the fact that it is customisable makes it suitable for renovations.
INFORMATION
BRAND
Are
PRODUCT TYPE
Lift
DETAIL
Like all A.R.E. Lifts, miniwatt® operates with the are smart power technology using just 130 watts and allowing it to be used even in the event of prolonged blackout.
PRODUCTION
Made in Italy
INSERTIONS PER HOUR
45
PIT
130 mm
HEADROOM
2000 mm
CAPACITY
up to 5 persone
LOAD CAPACITY
Up To 400 kg
REFERENCE NORM
Machinery directive 2006/42/CE EN81-41:2011 (where applicable)
TOP FLOOR LANDINGS
Can be installed where other Platform Lifts cannot: in attics, lofts or in all situations with top floor landings with height restrictions
MAXIMUM INRUSH CURRENT
0.7A
TRAVEL
24000 m
MAXIMUM SPEED
0.15 m/s
DOWNLOADS
↓ Data Sheet
ADVANTAGES
-Makes the most of the available space; -Can even be used by people who don’t like enclosed spaces; -Has minimal visual impact on its surroundings;
COMMITTED POWER
0.13 kW
LIFT POWER SUPPLY
Battery
