Are Mangusta Lift
ZEN-0 ELECTRIC LIFTMANGUSTA LIFT
MANGUSTA LIFT
The energy-saving lifting platform
Mangusta is an electrically battery-powered platform launched onto the market for the first time in 2009. Mangusta, like all our lifts, benefits from are smart power technology.
Mangusta consumes just 130w*, on a par with that needed to use everyday electrical appliances. There is no need, therefore, to change the supply contract stipulated, nor is there any need to install another meter with a higher power level.
Another advantages is that while in use, the energy produced by mangusta is not wasted as heat but stored in the batteries by optimising the performance levels of the lift and dramatically bringing down electricity supply costs.
The mangusta platform’s main power supply is based on the use of batteries. It is, therefore, possible to continue using the lift even if there is an unexpected power cut, which guarantees accessibility and safety at all times.
INFORMATION
SOLAR PANEL
The possibility of having the mangusta platform with solar panels means solar power can be used as a source of sustainable energy.
PRODUCT TYPE
Lift
CAPACITY
Up To 5 People
LIFT POWER SUPPLY
Battery
HEADROOM
2600 mm
PIT
150 mm
INSERTIONS PER HOUR
45
DOOR HEIGHT
2000 mm
LOAD
Up To 400 Kg
WITH BUS DOOR IN CABIN
The bellows doors in the cabin, for manual or automatic opening and closing. In the automatic version, the bellows door Information: panels are controlled by an electronic operator and the movement is controlled by an electronic mobile rib. The bus door allows for the automatic manoeuvre in cabin.
MAXIMUM INRUSH CURRENT
- 2 A
- 0.7 A
CABIN HEIGHT
- 2000 mm
- 2100 mm
MANOEUVRE IN CABIN
- Manual
- Automatic
TRAVEL
24000 m
REFERENCE NORM
EN81-20/50:2014
HEAD
- 2200 mm
- 2300 mm
- 2450 mm
NO DOOR IN CABIN
This version foresees that Information: the manoeuvre in cabin be manual (defined as "Person present").
AUTOMATIC DOORS
Automatic landing doors with sliding doors, opening and closing controlled by Information: an electronic operator with a programming keypad, available in various versions. In the version, Mangusta is completely automated.
STYLE
Mangusta can be perfectly adapted to the contours and style of the home, creating a new connection in perfect harmony with its surroundings.
DETAIL
The wide choice of materials and colours means that we can offer “tailor-made” solutions which are perfect for meeting all of your requirements.
MAXIMUM SPEED
- Up To 0.30 M/s
- Up To 0.15 M/s
COMMITTED POWER
- 0.23 kw
- 0.13 kw
DOWNLOADS
↓ Data Sheet
↓ Catalogue
GALLERY
