LIBELLULA GAZEBO
LIBELLULA GAZEBO
Aluminium structure for short events
INFROMATION
PVC
Class 2 flameproof PVC certified tarpaulin, which can be quickly fixed inside each eave gutter with 3/4 straps.
BRAND
Selvo Line
PRODUCT TYPE
Gazebo
PILLARS
4 Pillars made of anodized aluminium tubes (Ø 80 mm).
SHEET
4 perimeter self-bearing eave gutters made of anodized aluminium sheet. The eave gutters collect rainwater and convey it into the supporting pillars.
TUBES
4 pillars made of anodized aluminium tubes (Ø 80 mm).
DRAWING
The structure can be disassembled. For summer use only. Technical drawings and assembly diagrams.
STANDARD PILLAR HEIGHT
Standard pillar Height: 2.10 m.
ACCESSORIES & OPTIONS.
-Technical Report To Be Submitted To Authorities.
- PVC sliding side tarpaulins fitted with tracks, hooks for sliding of tarpaulins, and straps. Scallop pelmet.
- Ground fixing systems: concrete ballasts / plastic dome-shaped water-filled ballasts, screw anchors, pile shoes.
SIZE 3 x 3 m/ 3 x 4 m/ 4 x 4 m
- Weight :72 kg + tarp. 6 kg = 78kg
- Weight:82 kg + tarp. 8.5 = 90.5 kg
- Weight 85 kg + tarp. 10 kg = 95kg
