Sanmarco Heidelberg Roofing
HEIDELBERG ROOFING
HEIDELBERG ROOFING
The double lap along the edge increases protection from infiltrations generated by the phenomenon of rising damp.
INFORMATION
DIMENSION
- Lenght : 42,0 cm
- Width : 33,4 cm
BRAND
Sanmarco
PRODUCT TYPE
Roofing
UNITARY WEIGHT
4,3 kg
WEIGHT FOR SQM
43,9 ca kg
ROUNDED EDGES
Rounded edges at the base facilitate water runoff.
EFFECTIVE
Reinforcement profiles render the tile more effective.
PIECES FOR PALLET
240
PIECES FOR BUNDLE
40
COLLECTION
Heidelberg
PRODUCTION
Made In Italy
MINIMUM SLOPE
30% (18% in situazione protetta)*
WARRANTY
30 anni
COMPLETELY
The pilot hole for fastening is not completely through to facilitate attachment with nails or screws (NB: to be sealed with silicone upon use).
PRONOUNCED
The pronounced interlocking lateral profiles offer greater protection against water infiltration.
ACCENTED RIBBING
Accented ribbing at the base prevent sleet or pouring rain from infiltrating.
BATTEN GAUGE
31,0 – 34,5 cm
PIECES FOR SQM
10
ACCESSORIES
SPECIAL ACCESSORIES
Choosing the best flat and curved tiles is just the first step in creating a roof that’s healthy, safe and long-lasting.In addition to tiles, a wide range of accessories contribute to the correct functioning of the roof in technical terms, by guaranteeing excellent ventilation, high performance in any weather and compliance with the most rigorous safety standards. Functional accessories are designed specifically for each type of tile, and combine perfectly with the roof, including antique versions.
ROOFTOP ACCESSORIES
Made in terracotta, these accessories are designed for every type of tile used on the pitch of the roof, and can be built into the peak of the roof.
- Colmo tondo
- Finale di colmo tondo
- Tre vie per colmo tondo
- Quattro vie per colmo tondo
FUNCTIONAL ACCESSORIES
Special accessories not in terracotta but designed for each type of tile, which complete the roof, ensuring perfect details and excellent performance.
- Gancio tegola 40×60/30×50
- Fermaneve metallico
PITCH ACCESSORIES
Made in terracotta, these accessories are designed for every type of tile used on the pitch of the roof, and can be built into the roof: Ventilator, Snow guard, Antenna mount, Double wave, Left and Right side sections, Chimney bases and pots.
- Laterale sx taglio 90 mm
- Laterale sx taglio 120 mm
- Piastra di base in plastica
- Bocchettone sfiato lungo diam. 100/120 mm
- Bocchettone sfiato piatto diam. 100 mm
- Sistema adattatore uscita termica diam. 70/100 mm
- Manicotto di collegamento diam. 100/125 mm
- Tubo flessibile diam. 100/125 mm
- Mezzategola
- Aeratore
- Doppiaonda
- Uscita antenna
- Uscita tubo solare
- Laterale dx taglio 90 mm
- Laterale dx taglio 120 mm
