OSKURA UNICA PERGOLA
OSKURA UNICA PERGOLA
Oskura Unica is the exclusive bioclimatic pergola with totally independent orientation and slat packing operations.
New views, new horizons, new technological excellence!
Up to 115 degrees of orientation, total slat packing, dual independent operation, excellent weatherproofing… definitely unique, in name and in fact!
INFORMATION
PROFILE
- Post Profile : 150x150 mm
- Gutter Profile : 150x286 mm
DIMENSIONS
- Maximum Width : 4200 mm
- Maximum Depth : 6199 mm
WEIGHT
30 Kg/m2
MAX FOOTPRINT
1523 mm (Of Packed Slats)
SLAT PITCH
199 mm
SLAT THICKNESS
38 mm
ORIENTATION
- Slat Orientation : 0 - 115°
- Motor Orientation : Yes
CERTIFICATION
-Certification of the structure EN 1090-1:2009/a1:2011 : Yes
-Certified wind protection UNI EN 13659 : Classe 6 (Grade 10 On Beaufort Scale)
-Water tightness certification UNI EN 12208:2000 : Yes
BRAND
Sunroom
PRODUCT TYPE
Pergola
LED LIGHTING
Thanks to the LED lighting, it is possible to create a relaxing and sophisticated atmosphere. The white or RGB coloured LED strips are positioned along the perimeter of the pergola simply and quickly, without visible screws or wires.
SUNSCREEN FUNCTION
The sunscreen function, which allows orienting the slats from 0° to 115°, allows adjusting sunlight and heat inside the pergola, so that it can be enjoyed all year long.
PATENTED PRODUCT
Patented product, to guarantee safety, protection and durability over time.
FINISHES
CHARACTERISTICS
Having received a variety of patents and both for its mechanical and electronic components, the bioclimatic pergola Oskura Unica is the innovative solution in which orientation and packing operations can be found in a single product for the first time. Up to 115° of orientation, total slat packing, dual independent operation, excellent weatherproofing.
DOWNLOAD
↓ Data Sheet
PRODUCTION
Made in Italy
ROTATION & PACKING OPERATIONS
The dual independent rotation and packing operations will make you enjoy the beauty of being under a pergola!
RAINWATER DRAINAGE
The drainage system allows rainwater to be conveyed inside the perimeter gutters and then drained to the ground through the posts.
SWIVEL AND PACKING SLATS
Patented technology with dual independent operation for orientation up to 115 degrees and total slat packing , which promotes natural ventilation thanks to continuous air exchange, and mitigates the impact of heat by filtering direct sunlight.
SET UP
