Irsap Sequenze Radiator
SEQUENZE RADIATOR
SEQUENZE RADIATOR
The cuts break the shape and make it functional for use but above all they accentuate the perceived value, making it three-dimensional and sculptural.
The light and shadows reveal an intrinsic spirituality of the object. Sequenze is supplied with the innovative concealed hydraulic connection system installed directly in the company. Available in two models, sequenze s and sequenze l, with two thermal powers.
DESIGNERS
SILVANA ANGELETTI & DANIELE RUZZA
A couple in both personal and professional life, Silvana Angeletti was born in Rieti in 1969. Daniele Ruzza was born in Rome in 1967.
After graduating in industrial design, they began their partnership in February 1994 and opened their own design studio: angeletti ruzza design.
They took part in numerous competitions, winning prizes and commendation. They live and work in Rieti and cooperate with numerous prestigious Italian companies.
They have been collaborating with irsap since june 2006 and their research into proportion and linearity has led to three products that blend artistically into the home environment.
Sequenze, a radiator that speaks a contemporary language, with a neat and simple form that fits natural into any architectural environment. Shape and function, calm and simplicity are the inspirational muse of the new it is and m’ama thermo-artworks, made in 2017.
information
FINISHES
- Standard White
- Classic finished
- Special finished
- Other RAL colors
THERMAL POWER
386 Watt
PANEL
Radiating Panel
THREADING
1/2” Gas right threading
USE
Heating
PRESSURE
Maximum working pressure 4 bar
TEMPERATURE
Maximum working temperature 95°c
CERTIFICATIONS
FEATURES
- Low temperature
- Hydraulic radiator
- Valves Included
- Electric radiator available
PRODUCTION
Made in Italy
BRAND
Irsap
HEIGHT
845 mm
WIDTH
500 mm
DOWNLOADS
↓ Technical Sheet
↓ Catalog 2023
↓ Color chart 2023
↓ Installation Manual
↓ 3D Model Sequenze_l
↓ 3D Model Sequenze_S
CALCULATE THE POWER
How to choose the Oasi radiator for your home? How to know what is the right power to heat each room? Online thermal requirement allows you to identify the most suitable radiator for your living space
DESIGNERS
- Silvana Angeletti
- Daniele Ruzza
MODELS
- H. 845 Sequenze_L
- H. 1735 Sequenze_S
STANDARD EQUIPMENT
-Air Vent -Wall fixing system built into the product column -Innovative water connection system installed on the product complete with fittings for connection to copper pipes (12, 14 and 15 mm diameter) and multilayer pipes (14 x 2 thick and 16 x 2 thick)
TECHNICAL DRAWING
COLORS
-Quartz 1 -Beige Cream -Standard White -Ivory - RAL 1013 -Manhattan Grey -Red - RAL 3000 -Brown - RAL 8017 -Claret - RAL 3003 -Orange - RAL 2004 -Bluish Lilac - RAL 4005 -Woodland Green - RAL 6005 -Green Grass - RAL 6018 -Melon Yellow - RAL 1028 -Black - RAL 9005 -Pearl White -Edelweiss White -Sablé -Quartz 2 -Sunstone -Tobacco Brown -Flame Red -Azurite 3 -Medium Grey -Titanium Grey Metallic - RAL 9023 -Pearl Grey -Graphite Black -Hammered Grey -Satin Black -Matt White -Matt Black -Hammered Copper -Deep Blue - RAL 5004 -Agave -North Sea Blue -Ice -Matt Blue Dove - RAL 5014 -Matt Light Grey
TECHNICAL DATA
| MODEL | DEPTH (MM) | HEIGHT (MM) | WIDTH (MM) | CONN. CENTRE (MM) | WEIGHT (KG) | CAPACITY (LT) | ΔT=50°C (BTU/H) | EXPONENT |
|---|---|---|---|---|---|---|---|---|
| Sequenze S | 90.0 | 845 | 500 | 50 | 16.20 | 0.80 | 386.0 | 1.225 |
| Sequenze L | 90.0 | 1735 | 500 | 50 | 32.20 | 1.70 | 738.0 | 1.236 |
