Dibigroup Argo Plus Security Door
ARGO PLUS SECURITY DOOR
ARGO PLUS SECURITY DOOR
The most competitive security door class 3
Argo Plus is the most competitive security door anti-intrusion class 3, in terms of quality/price ratio.
Projected to answer to a market who looks for a fine product with a competitive price, it is available only as for internal installation in one standard dimension, with silver colour handle kit.
INFORMATION
ACOUSTIC INSULATION NOTES
- 30 dB with external panel 4mm thick
- 31 dB with external panel 10mm thick
BRAND
Dibigroup
PRODUCTION
Made In Italy
PRODUCT TYPE
Security Door
MATERIAL
Aluminium
LOCKING SYSTEMS
European cylinder locking system 1+3
European cylinder locking system with 1 red master key + 3 keys with card duplication. The lock is equipped with a hardened steel drill-proof plate. Outside, drill-proof defender.
INSTALLATION
Security doors for internal installation
THERMAL INSULATION
1,26 W/m²K
AIR PERMEABILITY
Class 3
ACOUSTIC INSULATION
30-31 dB
ANTI-INTRUSION
Class 3
HANDLES
- Poker knob
- Handle kit Poker
DIMENSIONS
- W 80 x H 200 - 210 cm
- W 85 x H 200 - 210 cm
- W 90 x H 200 - 210 cm
DOWNLOADS
↓ Complete File
↓ Certification YOUNG 2 - Acoustic insulation
↓ Certification YOUNG 2 - Resistance to wind load
↓ Certification Yuong 2 - Watertightness
↓ Certification Young 2- Thermal insulation
↓ Certification YOUNG 2 - Anti-intrusion
↓ Checklist for taking dimensions of security doors
↓ Guarantee for Di.Bi. products
↓ Form Installation Check
↓ Instruction manual for the installation of the Argo security door handle kit
↓ Installation Instruction for Subframe without Angle Stiffeners
INSTALLATION SOLUTIONS
TECHNICAL FEATURES
- 1. Subframe made with 20/10 thick galvanized steel with 12 anchors to wall
- 2. Frame made with 20/10 thick galvanized steel, painted brown Ral 8017 and complete with plastic covers, gasket and footers
- 3. Adjustable hinges on 3 axes with brown hinge covers
- 4. Doorleaf made of one galvanized steel sheets16/10 thick. Gasket in the perimeter of the leaf
- 5. Thermal insulation with high density polyurethane.
- 6. Wide-angle peephole
- 7. Security locking system with core with European cylinder with 1 master key + 5 keys with card equipped with a hardened steel drill-proof plate. Drill-proof defender
- 8. Lateral deadbolt
- 9. Upper deadbolt bar
- 10. Handle set in aluminium silver colour (inside handle + outside fixed knob)
- 11. Weatherstrip bar
- 12. 5 fixed deadbolts on the hinge side
