EWOLUTO® SINGLE SLIDING POCKET DOOR
EWOLUTO® SINGLE SLIDING POCKET DOOR
Sliding pocket door system for single door that allows to hang loads
A COUNTERFRAME AS STRONG AS A WALL
The smart solution that uses the entire wall
ECLISSE Ewoluto® Single is the pocket door system that allows to hang loads, such as wall units and shelves, directly on the wall section where it is hosted.
The wall that hosts the pocket becomes a standard wall.
THE COUNTERFRAME IS A FULLY-FLEDGED WALL
The patented ECLISSE technology solves the problem related to traditional sliding doors. The special structure transforms the counterframe into a real wall, expanding the possibilities for interior decor and furbishing.
EWOLUTO® AND DISABILITY
ECLISSE Ewoluto® Single does not interfere with the moving spaces and does not impede the passage of a wheelchair, which can slide freely and without any obstacles. It is also used to fix the security and support handles in the bathrooms.
INFROMATION
SIZE RANGING
- Width : 600 to 1200 mm
- Height : 1000 to 2400 mm
BRAND
Eclisse
PRODUCT TYPE
Double Sliding Door
PRODUCTION
Made In Italy
COLLECTION
Ewoluto®
DETAILS
ECLISSE Ewoluto® Single is supplied with passage size ranging from 600 to 1200 mm in width and from 1000 to 2400 mm in height, only in the solid wall version.
Using traditional mechanical wall anchors a capacity of 30 kg (600 mm from the wall) to 180 kg (against the wall) is guaranteed. A chemical wall anchorage has a better capacity: 60 kg (distance 600 mm from the wall) to 360 kg (against the wall). It is recalled that the maximum capacity of a handle bar, fixed with a chemical anchor (four-points anchorage) is 100 kg at a distance of 600 mm from the wall.
ACCESSORIES
HANDLES AND LOCK KITS
-Handles for glass doors,Handles for sliding and hinged glass doors
-Handles for wooden sliding doors
-Easy,Handles for doors with jambs
JAMBS AND ARCHITRAVES/FOR THE INSTALLER
-Jambs and architraves An elegant and professional finish for Classic sliding pocket door -Handhold A great help to the handling of the counterframe for solid wall
