Eclisse Telescopic Double Sliding Doors
TELESCOPIC DOUBLE SLIDING DOORS
TELESCOPIC DOUBLE SLIDING DOORS
Double sliding pocket door system for two parallel doors disappearing into the same pocket
OPENINGS WITHOUT LIMITS
Open space in the blink of an eye
Eclisse telescopic double is a special solution for sliding pocket doors that allows to enter a total of four parallel sliding door leaves (2+2 specular), covering large passage width.
FEATURES
DETAIL
-Eclisse telescopic double is supplied with passage size ranging from 2300 to 4700 mm in width and from 1000 to 2600 mm in height, both in the solid wall and in the stud wall version. -The solid wall version has an internal passage of 144 mm, while in the stud wall version the same is of 134 mm. In both versions, the thickness of the finished wall is 180 mm. -This counterframe is combined exclusively with wooden door panels. -The ideal accessory is definitely the Telescopic synchronisation.
ECLISSE TELESCOPIC DOUBLE - SOLID WALL VERSION
ECLISSE TELESCOPIC DOUBLE - STUD WALL VERSION
INFORMATION
BRAND
Eclisse
PRODUCT TYPE
Sliding Door
PRODUCTION
Made in Italy
COLLECTION
Telescopic
DIMENSIONS
- Width : 2300 to 4700 mm
- Height : 1000 to 2600 mm
HOW DOES IT WORK?
Eclisse telescopic double allows the sliding of four doors, two on each side of the opening. The mirrored movement of the sliding doors allows the opening of very large spaces with the minimum footprint.
WHY CHOOSE THIS PRODUCT?
Divide without separating. This sliding system optimizes the fluidity of the space between two adjoining environments, creating a single multi-functional space.No strict division, the two rooms become reconfigurable without constraint dictated by a classic hinged door. You can easily switch from one open space to two separate areas.
THICKNESS FINISHED WALL
180 mm
USE
Indoor
ACCESSORIES
DOORS
- Laminate Doors
- Semi-finished Tanganyika doors
HANDLES AND LOCK KITS/ JAMBS AND ARCHITRAVES
-Handles for wooden sliding doors : Easy handles for doors with jambs
-Jambs and architraves : An elegant and professional finish for Classic sliding pocket door
TREATMENTS & FOR THE INSTALLER
-Anti-corrosion treatment : The optional treatment for areas prone to moisture
-Handhold : A great help to the handling of the counterframe for solid wall
DEVICES
-Eclisse Bias® : The device that closes the sliding door silently and effortlessly -Telescopic synchronisation : The system that simultaneously and harmoniously move two parallel sliding doors -Anti-warp profile : The aluminum profile that prevents deformations, ensuring a smooth sliding
