Kone Transitmaster™ 120 Escalator
KONE TRANSITMASTER™ 120 ESCALATOR
KONE TRANSITMASTER™ 120 ESCALATOR
Designed for demanding people flow
The KONE TransitMaster™ 120 is a durable, eco-efficient escalator optimized for transit centers.
It provides a smooth, safe ride and a pleasant passenger experience, even under the most demanding traffic conditions.
INFORMATION
MOVEMENT
KONE TransVario chainless drive system minimises the risk of disconnection between motor and main shaft, as well as synchronising the movement of handrails and steps
BRAND
Kone
PRODUCT TYPE
Escalators
SPEED
0.75, 0.65, 0.5 m/s; 0.4 m/s with inverter
FEATURES
-Safety = peace of mind -Maximise your uptime with KONE 24/7 Connected Services -Reduced environmental impact -Plan for success with KONE as your partner
INCLINATION
-27.3º -30º -35º
VERTICAL RISE
Up To 15 M
OPERATIONAL ENVIRONMENT
-Indoor -Semi-outdoor -Full Outdoor
PROTECTION
Anti ride/anti surf barrier and extended balustrade increase passenger protection to prevent falls and reduce misuse of the unit
STEP WIDTH
-800 -1000 -1100 mm
CABLES
Halogen-free cables
QUALITY
Industry-leading reliability and quality
STEP WIDTH
-800 -1000mm
COLLECTION
TransitMaster
ENERGY
ISO Energy performance class A+++
GUIDANCE
Traffic signalisation, skirt lighting, yellow comb segment, step demarcations provide extra visual guidance for a smoother, safer ride
SAFETY
-Safety is the starting point for every KONE solution. KONE TransitMaster™ 120 conforms to all local and international safety codes. -We provide standard safety features including comb plate impact device switches and emergency stop buttons for passengers.
MAXIMISE YOUR UPTIME WITH KONE 24/7 CONNECTED SERVICES
-New KONE 24/7 Connected Services help to predict issues so that action can be taken before a breakdown occurs. -You benefit from improved communication and reporting on our maintenance work, providing you with full transparency and peace of mind.
ADDITIONAL SAFETY OPTIONS
-KONE Handrail Sanitiser and KONE Handrail Sanitiser Premium help prevent the spread of viruses and bacteria, and thereby encouraging passengers to hold the handrail -Audible alarms provide clear guidance on escalator travel direction and improve passengers’ attention -Extensive monitoring options with KONE Care ® 24/7 Connect
OPTIONS AND HIGHLIGHTS
ENERGY-EFFICIENCY
-Smart operational modes and inverter optimise energy consumption under different load conditions -Long lasting LED lighting is up to 80% more efficient than fluorescent lighting and lasts up to 10 times longer
SAFETY ENHANCEMENT
In addition to the standard safety features, we offer optional safety features including:
-New traffic signalisation solutions to provide extra guidance -Audible alarms provide clear guidance on escalator travel direction -Alarm for travel direction if passengers enter an escalator in the wrong direction -Fall-prevention barrier and extended balustrades provide additional passenger protection
DESIGN
High quality visual design for the best possible user experience:
-Innovative and attractive lighting solutions that also improve passenger guidance and safety -Wide range of design options to create stunning visual effects and perfectly match your building’s architecture -High quality component finishes and a harmonised look and feel throughout the KONE product portfolio
