Reynaers ConceptPatio 130 Sliding Door
ConceptPatio 130 Sliding Door
CONCEPTPATIO 130 SLIDING DOOR
ConceptPatio 130 is a qualitative (lift &) slide solution that balances price, performance and design.
The versatile aluminium system allows both architects and homeowners to create spaces without boundaries.
INFORMATION
PRODUCTION
Made in Belgium
PRODUCT TYPE
Door
BRAND
Reynaers
THERMAL INSULATION
Uf = 1.9 W/m²K
ACOUSTICS
High
COLLECTION
ConceptSystem
MATERIAL
Aluminium
MAX WEIGHT
- Vent : 300 kg
- Fixed : 300 kg
HEIGHT VENT
- Min:584mm
- Max : 2784mm
MAX. GLASS THICKNESS
43 mm
MIN. GLASS THICKNESS - VENT
4 mm
DEPTH
- Frame :139 mm
- Vent : 59 mm
- Frame Monorail :130 mm
- Frame 2-rail: 110 mm
ENERGY
High Insulation
SAFETY
- RC2
- WK2
- PAS 24
AIR-WATER-WIND
- Class 4 (600Pa)
- Class B5 (2000Pa)
- Class E750 (750Pa)
FEATURES
- Very complete offer with various opening types.
- Excellent balance between performance and affordability
- Unique low threshold renovation-friendly profile
FRAME-VENT WIDTH OPEN IN
Min. 68 mm
BURGLAR RESISTANCE
RC2 - RC3 -PAS 24
GLAZING METHOD
Dry glazing Siliconized glazing Internal glazing External glazing Glazing bead Structural Glued Glazing
GLAZING METHOD
- Dry glazing
- Siliconized glazing
- Internal glazing
- Glazing bead
THICKNESS
- Min. glass thickness - vent : 4 mm
- Max. glass thickness - vent : 52 mm
- Min. glass thickness - frame/element : 4 mm
- Max. glass thickness - frame/element : 52 mm
DETAIL
TYPE
The lift and slide variant of this system offers improved performances, and heavier vent weights.
DESIGN
2-RAIL: The standard variant offers a symmetrical design with the same profiles for sliding and fixed vents and 2 rails.
