CONCEPTSYSTEM 77 DOOR SYSTEM
CONCEPTSYSTEM 77 DOOR SYSTEM
Optimised safety and comfort
ConceptSystem 77 is a first-rate aluminium door system, available in a wide variety of opening types and design styles. The versatile solution offers the broadest range of safety requirements, including fireproof and bulletproof variants.
INFORMATION
AIR-WATER-WIND
- Class 4 (600Pa)
- Class 7A (300Pa)
- Class C2 (800Pa)
FEATURES
- Broad design and functional possibilities
- Well balanced price-quality-feature mix
- Available in extreme safety variants including bulletproof
ENERGY
High Insulation
MATERIAL
Aluminium
ENERGY
-Thermal insulation - Uf : 1.8 W/m²K
-Thermal insulation - Uw : 1.4 W/m²K
PRODUCTION
Made in Belgium
BRAND
Reynaers
PRODUCT TYPE
Windows
THERMAL INSULATION
Uf = 1.8 W/m²K
COMFORT
- Air tightness : Class 4 (600Pa)
- Water tightness : Class 7A (300Pa)
- Wind load resistance : Class C2 (800Pa)
- Opening & closing resistance : Class 8
SAFETY
- Impact resistance : I5/E5
- Fire resistance : EI₁ 30 EI₂ 30 EI₂ 60 EW 30
- Bullet resistance : FB4, FSG, FB6, Kalashnikov
FRAME-VENT WIDTH OPEN IN
Min. 68 mm
BURGLAR RESISTANCE
RC2 - RC3 -PAS 24
VENT DIMENSIONS
- Max. height of vent : 3000 mm
- Min. width of vent : 500 mm
- Max. width of vent : 1400 mm
GLAZING METHOD
- Dry glazing
- Siliconized glazing
- Internal glazing
- Glazing bead
HEIGHT VENT
Mam. 3000 mm
ACOUSTICS
High
THICKNESS
- Min. glass thickness - vent : 4 mm
- Max. glass thickness - vent : 52 mm
- Min. glass thickness - frame/element : 4 mm
- Max. glass thickness - frame/element : 52 mm
WEIGHT OF VENT
- Max. weight of vent : 551 lbs
- Max. weight of fixed part : 617 lbs
DEPTH
- Frame : 68 mm
- Vent : 68 mm
GLAZING
Rebate Height : 25 mm
ELEMENTS DIMENSIONS
Min. height of element : 535 mm
SIGHTLINES
- Min. frame width (inward opening) : 68 mm
- Min. vent width (inward opening) : 76 mm
- Min. frame-vent width (inward opening) : 150 mm
- Min. frame width (outward opening) : 42 mm
- Min. vent width (outward opening) : 102 mm
- Min. width T-profile : 76 mm
- Min. frame-vent width (outward opening) : 150 mm
PRODUCT OPTIONS
Personalise ConceptWall 60 with the following options :
-Balustrade : Safety can equal beauty.
-Softclose : Combines safety and comfort.
-Panic : Tried and tested, for peace of mind.
-Low Threshold : Easy access, cleaner look.
-Motorised : Comfortable to use, even remotely.
-Panic : Tried and tested, for peace of mind.
-Gutter : Better water performance, without adding thresholds.
-Concealed Hinges : The details are the design, concealed hinges are the finishing touch.
-Concealed Drainage : No more plastic cover caps, enjoy those clean lines.
-Flyscreen : Enjoy cool summer evenings, without losing sleep.
-Access Control : Making your home smart and connected.
-Zero Threshold : Entrance without boundaries, even with continuous flooring.
DETAIL
PANEL DOOR
The stylish panel door is available in several variants, including double-sided, and any size of looking glass.
FUNCTIONAL DOOR
The standard product offers a Functional design, which means it will fit any building style.
SOFTLINE
The Softline variant has been developed to have soft and smooth edges.
SAFETY
-Bulletproof : Some extreme situations require bullet resistance, and this variant offers it in various classes. -Fireproof : This variant helps to provide fire safety in several classes and configurations to ensure an extended and safe escape route during a fire. -Smokeproof : This variant is smokeproof, giving maximum opportunity to escape a burning building.
