Reynaers HiFinity Sliding System
HiFinity sliding system
HIFINITY SLIDING SYSTEM
The infinite view
HiFinity's ultra-slim profiles create seemingly endless transparent surfaces with a minimalist look.
The elegant aluminium sliding system combines an infinite view with impressive performances. The perfect choice for any low-energy contemporary building.
INFORMATION
PRODUCT TYPE
Sliding System
ENERGY
High Insulation
PRODUCTION
Made in Belgium
AIR TIGHTNESS
Class 4 (600Pa)
WIND LOAD RESISTANCE
Class C5 (2000Pa)
WATER TIGHTNESS
Class 9A (600Pa)
OPENING & CLOSING RESISTANCE
Class 3
BALUSTRADE
Safety can equal beauty.
BURGLAR RESISTANCE
- RC2 -WK2 -PAS 24
CONCEALED DRAINAGE
No more plastic cover caps, enjoy those clean lines.
GUTTER
Better water performance, without adding thresholds.
FLYSCREEN
Enjoy cool summer evenings, without losing sleep.
THERMAL INSULATION
- Uf = 2 W/m²K
- Uw1=0.87 W/m²K
MOTORISED
Comfortable to use, even remotely.
ACCESS CONTROL
Making your home smart and connected.
DESIGN 2 ROLL
The standard variant is suitable for double glazing.
OPEN CORENER
The open corner variant gives you much more design freedom and a more spacious feel.
GLASS CORNER
Glass to glass connection without profiles obstructing the view
HIGH INSULATION
The High Insulation variant can hold triple glazing (or thicker acoutstic double glazing), for and even better thermal and/or acoustic performance.
CERTIFICATIONS
ZERO THRESHOLD
Entrance without boundaries, even with continuous flooring.
SIGHTLINES
- Min. width 4-pane67 mm
- Min. width meeting section35 mm
- Min. width T-profile35 mm
- Min. visible width (interior view)8 mm
- Min. visible width (exterior view)8 mm
- Depth frame148 mm
- Depth Vent44 mm
- Depth frame-vent148 mm
- Depth frame 2-rail148 mm
- Depth frame 3-rail236 mm
PROPERTIES
- Min. height of element : 1901 mm
- Max. height of element : 4165 mm
- Min. width of element : 2097 mm
- Min. height of vent : 1800 mm
- Max. height of vent : 4000 mm
- Min. width of vent : 1000 mm
- Max. width of vent : 3500 mm
- Max. weight of vent : 1653 lbs
- Max. weight of fixed part : 2645 lbs
- Max. weight of glass : 2645 lbs
GLAZING METHOD
- Rebate height : 17 mm
- Glazing methodEnvelope glazingStructural Glued Glazing
- Min. glass thickness - frame/element : 36 mm
- Max. glass thickness - frame/element : 54 mm
- Min. glass thickness - vent : 36 mm
- Max. glass thickness - vent : 54 mm
