Living Concrete Rivet Concrete Wall Panels
Rivet Concrete Wall Panels
RIVET CONCRETE WALL PANELS
Our GRC Rivet wall panels are a great choice for anyone who wants to enjoy an innovative design which can be easily incorporated into an existing space or new construction project. Our concrete is manufactured using our bespoke process which allows us to make exceptionally thin panels which have a lot of strength, fantastic UV stability and a superior mechanical resistance.
Our tiles are manufactured using our bespoke process, and are made with cement, a special type of sand, additives and UV stable pigments. The result is a tile which has a high level of hardness and longer lifespan than other products on the market, so they’re suitable for any setting.
The Rivet panels are great for both indoor and outdoor use, making them perfect for transforming spaces into a contemporary area. We pre-seal all our panels and offer you a complete installation service for all the products we sell.
INFORMATION
BTX CONCRETE FEATURES
-Suitable for floor and wall installation both indoor and outdoor
- Large format / ultra thin tiles with superior strength
- High mechanical resistance and UV stability
- Available in different textures and colours
PRODUCTION
Made In London
CATEGORY
Concrete panels
MINIMUM ORDER
10m2
WEIGHT
18kg/m2/10mm
COMPOSITION
- Cement
- Selected sand
- Specially designed additives and UV stable pigments
The GRC Ultra High Performance Concrete panels stand out because of their versatility, durability and high hardness, making them suitable for all types of applications.
CONSIDERATIONS BEFORE INSTALLING BTX TILES
-Keep packaged until installation -Do not force the tiles over uneven surfaces -Always store horizontally -Do not place loads on the tiles -Level the sub-floor correctly before starting the installation (+/- 2 mm in 3 m) -Place the tiles on the floor to choose your colour composition - Leave at least 5 mm for joints -BTX tiles are not rectified, they can have variations of 0.6%
FINISHES
Unsealed or a choice or Matt, Satin or Gloss (we recommend sealing to limit staining).
USE
Internal or external
DOWNLOAD
↓ Product Sheet
MECHANICAL PROPERTIES
- Yield strength (modulus of rupture): 5-8 mpa
- Tensile strength (modulus of rupture): 2-5 mpa
- Compressive strength: 20-30 mpa
- Impact strength: 5-10 KJ/m2
- Thermal expansion coefficient: 20 x 10-6/°C
- Absorption: Low water permeability
- Dorry wear: 2.5 mm
STANDARD SIZES
We offer a selection of standard panel sizes for you to choose from. These panels can also be cut to size to suit any space. - 1200 × 600 x 10 mm
STORAGE
-Keep in a dry, clean space in the original packaging -Panels should be kept in a horizontal way
INSTALLATION
Adhesive or bracket system
MATERIAL
Hand-cast concrete -Brushed steel
TOLERANCES
- Thickness +/-5%
- Side straightness: +/-0.5% Orthogonality: +/-0.6% Planimetry: +/-0.5% Length and width +/-0.6%
COLOUR VARIATIONS
Because of its cementitious composition the colour of GRC panels may have different textures and tones within the same panel and / or in comparison to other panels in the same batch. Our colour selection chart is for reference use only and the colours are as close as possible to the original colours.
CLEANING AND MAINTENANCE
-Clean with fresh water and a neutral pH detergent -Do not use any aggressive cleaning agents or any other chemicals that are reactive to concrete or sealant-To clean specific stains do not use abrasive materials -Do not leave standing water on the surface -Do not leave stains to dry, as they may permanently stain the surface
-For outdoor apply sealant periodically depending on usage -Sweep or vacuum the surface regularly to remove all dirt and dust
VERIFICATION OF THE AESTHETIC APPEARANCE
Please check and ensure that you are happy with the delivered product and there are no apparent visible defects. If any issues are detected do not start the installation and contact supplier immediately. No claims will be accepted after tiles have been installed.
APPLICATIONS
-BTX Ultra High Performance Concrete is lighter and stronger than conventional concrete -large format ultra thin pre-cast tiles-High mechanical resistance and UV stability -Easy made of natural materials -Great thermal conductivit-Available in many -Bespoke sizes and great alternative to poured polished concrete -Fast installation
TEXTURES & colours
SURFACE TEXTURES
Silk (Smooth) – Rough (Pitted) – Sandblast (Rustic)
COLOURS
This selection of colours is for reference use only and are as similar as possible to the real colours. Because we work with only natural materials such as cement, sand and water, these may undergo changes in colour and tone.
