Baldassar Olimpia Fences

The fence consists of 124 x 50 / 100 mm mesh and a 25 x 3 mm bearing bar, comprising horizontal bearing bars with a rectangular cross-section and connecting round cross-beam bars. The side band – connected via wire welding – ensures a high resistance and long-lasting quality.

COATING

A polyester resin powder coating – suitable for outdoor use – is applied on the hot dip-galvanised material post-processing.

ACCESSORIES

Posts : The posts for the Olimpia fence model are made from an IPE 100 profile. They are available in a screw-in or screw-on version.

ITEM SPECIFICATIONS

The Baldassar Olimpia fence model consists of electro-welded grating panels in S235JR (UNI EN 10025) steel, comprising: a 124 x 50 mm mesh lower panel, horizontal bearing bars with a 25 x 3 mm cross-section, vertical cross wire with a 5 mm diameter and a steel side banding bar with a 25 x 3 mm cross-section which is hand wire-welded, complete with an upper panel connection system. 124 x 100 mm mesh upper panel, horizontal bearing bars with a 25 x 3 mm cross-section, vertical round crosswire with a 5 mm diameter and a steel side banding bar with a 25 x 3 mm diameter that has been manually wire-welded to increase the product’s resistance. The model boasts a stiffening tube which is welded directly to the top of the panel and a lower panel connection system. It comes with posts made of IPE 100 profiles and M10 round head bolts with a shear lock nut. All the elements are hot dip-galvanised in accordance with the UNI EN ISO 1461 standard.

TECHNICAL DRAWING

TECHNICAL DATA
