CISAR FENCES
Cisar is a modular fence for those who love a modern, clean and minimalist style.
Cisar is a modular fence that serves as a street furniture element in industrial and commercial settings, by blending in with the surrounding environment.
It is also installed in residential settings for those who love a modern, clean and minimalist style. It comprises C-shaped horizontal profiles (30 x 45 x 30 mm) and vertical round tube profiles (20/25 mm diameter), welded directly to the C-shaped profiles..
INFORMATION
ITEM SPECIFICATIONS
The Baldassar Cisar fence model consists of 2 C-shaped horizontal profiles with a 30 x 45 x 30 mm cross-section and 20/25 mm-diameter round tubes, welded directly to the C-shaped profiles. It comes with steel posts comprising a 60 x 7 mm cross-section round top bar, in addition to M8 x 30 stainless steel bolts. All the elements are hot dip-galvanised in accordance with the UNI EN ISO 1461 standard.
DOWNLOADS
↓ Data Sheet
↓ Catalogue
BRAND
Baldassar
PRODUCT TYPE
Fences
MATERIAL
S 235 JR (UNI EN 10025:1995) steel
PRODUCTION
Made In Italy
COATING
A polyester resin powder coating – suitable for outdoor use – is applied on the hot dip-galvanised material post-processing.
STANDARD SURFACE TREATMENT
Hot dip-galvanised post-processing in accordance with UNI ISO 1461:2009
ACCESSORIES AND OPTIONAL EXTRAS
- M8 x 30 round head stainless steel bolt with lock nut
- M8 x 30 stainless steel bolt with hex nut
- Other posts
TECHNICAL DRAWING
TECHNICAL DATA
| PANEL - H2 HEIGHT (MM) | PANEL -L=1992 WEIGHT (KG/EACH) | POST - SECTION (MM) | SCREW-ON POST - H3 HEIGHT (MM) | SCREW-ON POST - WEIGHT (KG/EACH) | CONCRETE-IN POST - H1 HEIGHT (MM) | CONCRETE-IN POST - WEIGHT (KG/EACH) |
|---|---|---|---|---|---|---|
| 910 | 17,40 | 60 x 7 | 1000 | 4,10 | 1180 | 4,20 |
| 1040 | 18,90 | 60 x 7 | 1130 | 4,50 | 1315 | 4,70 |
| 1180 | 20,40 | 60 x 7 | 1265 | 5,00 | 1450 | 5,20 |
| 1305 | 21,70 | 60 x 7 | 1395 | 5,50 | 1580 | 5,60 |
| 1440 | 23,30 | 60 x 7 | 1525 | 5,90 | 1710 | 6,10 |
| 2000* | 35,00 | 60 x 7 | 2090 | 8,15 | 2270 | 8,40 |
| 2000* | 35,00 | 80 x 8 | 2090 | 12,60 | 2270 | 12,70 |
AVAILABLE RAL COLOURS
- Upon Request : 6029, 9010, 9005, 5010, 1023, 3002, 7016 ,6005
