Vasco ONI O-NP Bathroom radiators
ONI O-NP Bathroom radiators
ONI O-NP BATHROOM RADIATORS
Wafer-thin, wonderfully warm and a delight for the eye. The new Vasco Oni extends the boundaries of radiator design.
A copper heating tube with minimal water content is integrated into the ultra-thin aluminium front plate (with optional cut-outs for hanging towels)
So this ´floating´ flat radiator is not only beautiful to look at, but also extremely efficient and energy-saving. Ideal in combination with low temperature systems. Model O-NP with its completely flat front plate is beautiful to look at and the ultra-thin design gives it a ´floating effect´.
It embodies the absolute essence and is free of any superfluity. In this way it perfectly matches every interior. Authentic, inspiring and effective. Not just today, but also thirty years from now. A timeless eyecatcher!
information
BRAND
Vasco
PRODUCT TYPE
Bathroom radiators
DESIGN
- Timeless design, fits in every interior
- Austere design with gently rounded-off corners
TUBES
Lightweight aluminium plate with copper heating tube
RADIATIONS
Optimal thermal radiation and fast warm-up time
SHAPE
With or without rounded-off cut-outs for hanging towels
TECHNICAL
-The pathway for the heating tube is milled out to 2 mm below the surface. The tube is then pressed into the aluminium plate. -KTL priming coat, powder coating -Standard operating pressure: 6 bar -Maximum operating temperature: 120°C
OTHER DETAILS
-Ultra-thin design (8 mm) -Sustainable technology
TYPE
-O-P: with one (1400 mm) or two (1800/2000 mm) cut-outs for hanging towels -O-NP: without cut-outs)
COLORS SYSTEM
Available in virtually all Vasco colours
ELECTRICAL
-Pure electrical radiator prefi lled
-Mixed radiator
COMBINATIONS
Ideal in combination with low temperature systems
BRACKETS
Wall brackets standard
COLOURS
Standard colour S600 (fi ne texture white) (RAL 9016: no extra charge 15%)
CONNECTIONS
-One-point connection for one-pipe system - One-point connection for two-pipe system - Two-point connection for one-pipe system (connection by way of the central connection) (see p. 342) - Two-point connection for two-pipe system (standard) (see p. 342) -Integrated valve
COLORS
BLUE GREEN
METALLIC GREY
NATURAL GREY
NOBLE COLOURS
PURE GREY
UNI COLOURS
WHITE BLACK
-9826 Brown Black -9827 Grey Anthracite -RAL 9001 Cream White -RAL 9005 Jet Black -RAL 9010 Pure White
-RAL 9016 Traffic White -S600 White Fine Texture
-Transparent Coating 9990 -White
