Cupa Pizarras Cupa 2 - Roofing Slates
CUPA 2 - Roofing Slates
CUPA 2 - ROOFING SLATES
CUPA PIZARRAS has been producing the most complete range of natural slate for roofing and facade since 1892.
Non-carbonated slate formed by tectonic compression. Dark grey slate with thin laminations and a smooth surface.
INFORMATION
BRAND
Cupa Pizarras
PROPERTIES
Waterproof
FREEZE THAW TEST
Fulfill < 0.6%
SO2 EXPOSURE TEST
S1
CONTENTS OF CARBONATE NON CARBONATED
0,60% Fulfill (< 1,5%)
CERTIFICATIONS
- European Standard: EN 12326
- French Specifications: NF44/03 - Nº33235
- Belgian Specifications: ATG/H652
- British Standard: BS 680 Part 2
MOR CHARACTERISTIC
Longitudinal 49,6 MPA
OPERATIONS START DATE
Operating since 1972
MOR CHARACTERISTIC
Longitudinal 40.8 MPA
ORIGIN
- Riodolas mine
- Carballeda de Valdeorras Ourense (Spain).
COLOR
INTERNATIONAL CERTIFICATIONS
CUPA 2 roofing slates meet the following international standards.
CHARACTERISTICS
- Riven Surface
- Dark Grey Slate
- Non-carbonated
- Formed By Tectonic Compression
APPLICATIONS
-New roofs -Restorations
DOWNLOAD
↓ Technical Sheet
AVERAGE THICKNESS
3.5 mm,5 mm, 6 mm and 7.5 mm.
FORMAT
- Square
- Half moon
- Shuppen
- Spitzort,
- Spitzwinkel
- Rectangular
- Waben, fischuppen, 90º Sawn
SELECTIONS
- R
- H
- Natural
DIMENSIONS
- Between: 20 x 20 cm and 60 x 45 cm
- Thickness: 3.4mm, 5mm, 6mm and 7.5mm
USE
Roofing
WATER ABSORPTION
0,17% Code: W1 (< 0,4%)
FORMATS
Multiple shapes available. Rectangular is the most common model.
