CAPRI FACING BRICK
CAPRI FACING BRICK
A hand moulded brick with red and blue
The (non-perforated) facing brick is sanded on five sides. The surface may be given a frog (a slanted oblong groove) on its bed.
The structure looks rugged with fine and irregular grooves in the sandy surface. The firing process takes place in a gas-heated tunnel kiln.
The brick has a red base, with hues ranging from brown red with white shadings and blue sediments. The colours shown are a near reflection of reality.
INFORMATION
BRAND
Nelissen
PRODUCTION
Made in Belgium
USE
Masonry Construction
MATERIAL
Bricks
THERMAL CONDUCTIVITY(Λ10,DRY,MAT(90,90)
S2 : 0.59 W/mK
THERMAL CONDUCTIVITY EN1745 ANNEX A
S1 : 0.55 W/mK
CHARACTERISTICS
- Solid Brick
- Color Variations
- Irregular Surface
TOLERANCE CATEGORY
T2
WATER VAPOUR PERMEABILITY
5/10
APPLICATIONS
- Exterior and Interior
- New Projects
- Renovations
GROSS DRY DENSITY
D1 : 1630 Kg/m³
WATER ABSORPTION
14 %
INITIAL WATER ABSORPTION
1,5<IW<=4 Kg/(m².min)
ACTIVE SOLUBLE SALTS
S1
DIMENSIONS
| SIZES | M50 | M65 | N70/4 | N70/5 | N70/7 | NNF | RF | WV50 | WV65 |
|---|---|---|---|---|---|---|---|---|---|
| Length | 188 mm | 188 mm | 239 mm | 239 mm | 240 mm | 241 mm | 208 mm | 209 mm | 213 mm |
| Width | 88 mm | 88 mm | 72 mm | 72 mm | 70 mm | 108 mm | 100 mm | 100 mm | 101 mm |
| Height | 51 mm | 64 mm | 40 mm | 50 mm | 70 mm | 73 mm | 40 mm | 49 mm | 65 mm |
