Hunter Douglas Architectural Combi-line Ceiling
COMBI-LINE CEILING
COMBI-LINE CEILING
Combi-line I Creative Ceiling Design Carrier System.
The new innovative Combi-Line system is a revolutionary neDesign & Inspirationw ceiling concept that allows architects to combine three different panel types into one design. Wood, HeartFelt® fabric and metal ceiling panels can now all be incorporated into one ceiling using a variety of modulations.
INFORMATION
FIRE RETARDENT
See Individual Material Data
CHARACTERISTICS
Fixes Different Varieties Of Hunter Douglas Panels, Enables Mixed Panels In One Ceiling Design
APPLICATIONS
Ceiling Carrier System
USE
Interiors
INFORMATION
Combi-Line is suitable for all building sectors : Corporate, Transport (airports, metro, bus, train stations), Retail, Leisure, Public spaces, Hospitality, Healthcare, Education or Residential. Please contact us to discuss your requirements.
PATTERNS
PLAY
Combination of materials in 1 module.
REPEAT
Combination of materials in variable modules and variable densities.
PAUSE
Random patterns with one or more materials featuring ruptured lines.
WEIGHT
Depends On Material And Module
WHAT IS COMBI-LINE
Combi-Line features a unique carrier rail system that is fitted with a variety of clips that are designed to support a combination of linear metal, wood and HeartFelt® fabric panels. This enables three different ceiling panel styles to be fitted onto a single carrier in any order and in any modulation.
MATERIAL
- Carrier : Steel
- Ceiling Panels : Wood, Metal & Nonwoven
- Thermo formable PES-fibers
ACOUSTICS
The acoustic performance in an office space, school or public building contributes to our well-being. Poor acoustics can affect health, communication, safety, productivity and learning. Hunter Douglas high performance acoustic ceiling products are the best solution to deliver outstanding acoustic performance, comfort and an aesthetically pleasing environment. With the Combi Line ceiling system an absorption value (αw) up to 0.70 can be obtained, depending on the ceiling and panel configuration.
CERTIFICATION
- Indoor Air Comfort Gold
- French VOC-regulation class A+
- Cradle to Cradle™ Level Bronze (Metal + HeartFelt®)
- Oeko-tex Standard 100 klasse IV (HeartFelt®)
- SundaHus Miljödata klasse A (HeartFelt®)
- GreenGuard Gold
DETAILS
- Combi-Line allows you to mix and match with a range of Hunter Douglas metal, wood and HeartFelt® panels.
- Easy access to the plenum for maintenance, the panels can be dismounted individually.
- Designers have the ability to create a unique pattern with more than one ceiling panel type.
- Combi-Line is available with HeartFelt 30HL60, metal 30 BD/BXD and veneered wood 30WL60 linear panels.
DOWNLAODS
↓ Combi Line CAD 2D
↓ Combi Line CAD 3D
↓ Brochure Combi-Line
↓ Technical leaflet Combi-Line
PRODUCT DETAILS
MATERIAL CHARACTERISTICS
The new Combi-Line carrier system features a rail fitted with clips that can accommodate metal, wood grill and HeartFelt panels to be fitted to a single carrier all at the same time.
This provides the architect with a variety of design opportunities. Endless combinations are possible that include, random patterns with linear interruptions together with open positions in the grid mixed with non stand modulation.
Designers have the opportunity to mix and match ceiling panels with different materials. Combi-line is available with HeartFelt 30HL60, metal 30 BD/BXD and veneered wood 30WL60 linear panels.
COLOURS & FINISHES
COLOURS & FINISHES
The modular nature of the Combi-Line system enables the designer to create a combination of four colours with four completely different ceiling styles, each with its own unique colour and finish. There is a wide selection of materials and products available to enable the architects to be truly creative with the room space he or she is creating. Each style group consists of a selection of materials that helps create a mood board and a matching space where the product can be applied.
MODEST ELEGANCE : A style that matches interiors characterized by understated luxury.
Material Choice : Dark matt metal, luxurious wood types such as walnut and oak and deep dark HeartFelt® shades
NATURAL PURITY : A style that matches a pure and natural interior.
Material choice : Warm umber tones HeartFelt®, warm deep wood tones such as walnut and cherry, with even the metal range available in similar tones
LINEAR MINIMALIST : A style that matches the sleek minimalist interior.
- Material choice : Greyed shades of HeartFelt® combined with silver, black and white metal.
SOFT SCANDINAVIAN : A style that is characterized by light colours and a soft yet business-like minimal appearance.
Material choice : Light metallic colours interspersed with soft greyish HeartFelt® shades and light wood
