Western Window Systems Series 670 Hinged Window
SERIES 670 HINGED WINDOW
SERIES 670 HINGED WINDOW
Choose a style. Create a custom opening. Integrate with a hinged door, sliding door, or fixed window wall.
The Series 670 Hinged Window from Western Window Systems combines clean design and optimal performance with the same superior craftsmanship found in our sliding and folding doors.
The Series 670 Hinged Window is also available for mulling above or below an operable window or to maintain consistent sightlines in a room. It’s all the inspiration you need for your next project. And the one after that.
INFORMATION
CERTIFICATION
- NFRC
- AAMA
MATERIAL
Glass
WINDOW TYPE
Hinged
SIZES
- Width : 16”- 42”
- Height : 16” - 120”
APPLICATIONS
- Commercial
- Corporate
- Hospitality
- Window Systems For Residential
PUSH-OUT CASEMENT
- Large vent sizes
- Low-E glass, dual-paned
- Hidden multi-point locking system
BRAND
Western Window Systems
PRODUCT CODE
Series 670
HARDWARE
CHARACTERISTICS
- Low-maintenance
- Features for improved energy performance
- Customizable options, sloped sill for drainage
- Can be matched to other products from the same company
USE
External Windows
PRODUCTION
Made in USA
PROPERTIES
- Energy Efficiency
- UV Protection
- Thermal Insulation
AREA OF CONSTRUCTION
Interior / Exterior
PERFORMANCE
Optimal
HOOPER
- Large vent sizes
- Low-E glass, dual-paned
- Highly configurable
SCREENING
Screens for Western Window Systems Series 670 Window Line are designed to provide protection from outside pests while complementing the clean, contemporary lines of the window. Manufactured from extruded aluminum for durability, they employ an easy-to-use concealed clip system. Screen frames are finished to match the window’s frame color. Not available for push-out casement.
CASEMENT AND AWNING
- Large vent sizes
- Contemporary roto operator
- Low-E glass, dual-paned
- Highly configurable
- Hidden multi-point locking system
FINISHES
Aluminum finishes for Western Window Systems’ Series 670 Hinged Window are available in-stock, as designer selections, or customized to match nearly any color.
-In Stock Finish Bronze Anodized : Western Grey, White, Navajo White, Warmtone, Stonish Beige
-In Stoxk Finish Satin Anodized : Bison Beige, Autumn Night, Briar, Hillside Bronze, Cinnamon Toast
SERIES
SERIES 670 CASEMENT
The Series 670 Casement from Western Window Systems hinges on the side, swings outward to the left or right, and provides excellent ventilation.
- 4.5″ frame depth
- Available in widths from 16″ to 42″ or heights from 16″ to 120″
- Sloped sill for improved water drainage
- Optional raked head window shape
- Thermally broken aluminum
SERIES 670 PUSH-OUT CASEMENT
Western Window Systems’ Series 670 Push-Out Casement combines the traditional appeal of a push-out window with modern efficiencies. It opens easily with the turn of the handle and a light push. Stainless-steel, four-bar hinges with an adjustable tensioning device keep the sash in place when open.
- 4.5″ frame depth
- Sloped sill for improved water drainage
- Available in widths from 18″ to 36″ or heights from 18″ to 72
- Durable locking handles available in brushed nickel
- Thermally broken aluminum
SERIES 670 AWNING
The Series 670 Awning from Western Window Systems hinges on the top, opens outward, and is typically wider than it is tall. Ideal for providing natural light and ventilation to small areas, it saves space by opening out from the bottom.
- Sloped sill for improved water drainage
- 4.5″ frame depth
- Double scissor-arm operator
- Available in widths from 21″ to 60″ or heights from 18″ to 48
- Thermally broken aluminum
- Push-out version available, handle available in brushed nickel
SERIES 670 HOPPER
Western Window Systems’ Series 670 Hopper hinges on the bottom and opens from the top. Hopper windows are the perfect solution in places where there is limited space for a window to extend to the outside.
- 4.5″ frame depth
- Sloped sill for improved water drainage
- Locks with a pawl handle or ring pull, available in brushed nickel
- Available in widths from 18″ to 60″ or heights from 20″ to 48″- Thermally broken aluminum
