ASI Architectural Strandtec Ceilings & Walls
Strandtec Ceilings & Walls
STRANDTEC CEILINGS & WALLS
StrandTec is now a leader in the acoustical-panel products category with eco-friendliness, high-performance, and cost-effective qualities.
StrandTec (wood fiber) performs by absorbing sound while thermally insulating.
Ecologically, it is simple to produce and panels are available in size and color variations that can be designed to fit nearly any décor.
These eco-friendly wood fiber panels not only liven up a room with design variety, but they also reduce echo and reverberation by sound absorption. Wood fiber panels can transform the aesthetics and acoustics of any interior space.
information
LIGHT REFLECTANCE
- Primed Clear : 50%
- Primed White : 70%
WEIGHT
- 1″ = 2 lbs./sf
- 1-3/8″ = 3 lbs./sf
- 2″ = 4 lbs./sf
CHARACTERISTICS
-Fast and easy installation -Washable -Abuse-resistant -Anodized, Acoustical Absorption
MOUNTING OPTIONS
StrandTec Wall Panels are to be mechanically fastened to an approved substrate.
CORE
- Cementitious wood fiber consists of wood fibers
- Portland cement, and water. Wood fiber is a natural material and color variations are common.
APPEARANCE & COLOR
-Manufactured from natural products
- Fire-resistant
- Mechanical fasteners
- An economical alternative to fiberglass, foam, polystyrene & rock wool
APPLICATION
-Bars -Restaurants -Sports and entertainment venues -Schools music practice and band rooms -Pools -Convention centers -Gymnasiums -Houses of worship -Manufacturing and industrial facilities -Corporate spaces -Airports, and more.
ACOUSTICAL PERFORMANCE
| NRCPanel Thickness | MountDirect AttachNo airspace | 3/4″ Airspace | 1″ Cellulose Acoustical Backer | 2″ Cellulose Acoustical Backer | CeilingNo Backer | 1″ Cellulose Acoustical Backer | 2″ Cellulose Acoustical Backer |
|---|---|---|---|---|---|---|---|
| 5/8″ | 0.5 | 0.9 | |||||
| 1″ | 0.45 | 0.5 | 0.8 | 0.85 | 0.4 | 0.8 | 0.85 |
| 1-3/8″ | 0.55 | 0.6 | 0.8 | 0.9 | 0.6 | 0.85 | 0.9 |
| 2″ | 0.75 | 0.75 | 0.9 | 0.95 | 0.75 | 0.95 | 0.95 |
SIZE
| Thickness | Width | Length | Edge Detail | Factory Finish |
|---|---|---|---|---|
| 1″ | 24″ | 48″, 96″ | Bevel, Square | Primed Clear, Primed White, Painted |
| 1-3/8″ | 24” | 48″, 96″ | Bevel, Square | Primed Clear, Primed White, Painted |
| 2″ | 24” | 48″, 96″ | Bevel, Square | Primed Clear, Primed White, Painted |
Available options
STRANDTEC DIRECT ATTACH
Panels are face fastened for fast easy installation
STRANDTEC LAY-IN
- Standard panel sizes can be field cut to fit irregular shaped installations
- Lays in to HD 15/16” T-bar grid for 100% accessibility
STRANDTEC TEGULAR LAY-IN
Standard panel sizes can be field cut to fit irregular shaped installations
- Lays in to HD 15/16” T-bar grid for 100% accessibility
- Tegular Lay-In panels have a 1” reveal
STRANDTEC TEGULAR LAY-IN
Panels can be mixed and matched for unique installations
STRANDTEC BACKFILL
Panels are back loaded with an acoustical backer for higher NRC
STRANDTEC DESIGNS
Panels have different patterns that can be used alone or together to achieve different appearances and designs
STRANDTEC CLOUD
Panels accept standard 15/16” HD T-Bar grid for easy installation
STRANDTEC WRAPPED
Several face options provide a number of design options
STRANDTEC BAFFLE
Suspended installation through reinforced eye
