THE RIBBON SOAP DISPENSER
THE RIBBON SOAP DISPENSER
Fully compatible with the The Splash Lab Soap Refill System, the automatic foaming nozzle reliably produces a precise dose of soap every time. The system is easily maintained, with the foaming nozzle simple and quick to replace.
INFORMATION
PRODUCTION
Made in USA
USE
Bathroom Accessories
CERTIFICATION
- LEED v4
- ADA | Award: Good Design 2014
COMPLIANT
- ADA Compliant
- LEED Compliant
WARRANTY
3 years parts and 1 year labour (from date of purchase)
FORMAT
Deck-mounted
DOSES OF SOAP
1.000
PUMP MOTOR LIFE
3,000 hours of usage
COMFORT DELAY
2 seconds
FINISHES
WEIGHT
2lb 3oz
SENSOR
IR sensor-activated foam-soap
ACCESS REQUIREMENTS
Solenoids, isolation valves and transformers must be accessible at all times for servicing
SOAP VISCOSITY
Foam soap - <10cPs. Not suitable for liquid soaps, alcohol gels or hand sanitizers.
SENSOR RANGE
- Preset 5" (adjustable).
- Min range 3" +/-20%
- Max range 5.9" +/-20%
MINIMUM OPERATING PRESSURE
7 - 87 psi dynamic pressure
FLOW RATE
0.35 GPM or 0.5 GPM
POWER SUPPLY
- Input : 100 - 240V AC; 50 - 60Hz; 1.2A
- Output : 12V DC; 1A; 12W max Waterproof connector to sensor lead
DESIGN
Unique design is part of a suite of three complementary products
CABLING
3 amp fused spur to IP68 rated transformer; low voltage push fit connector to faucet
STAINLESS STEEL GRADE
AISI 304 Stainless Steel
COUNTERTOP THICKNESS
1 3/8"
SECURITY CUT-OFF
- 60 seconds
- To flush 20 seconds after 24 hours of no usage
TECHNICAL DRAWING
CHARACTERISTICS
-Modular -Eco-friendly -Clean aesthetic -Easy specification -Simple-installation -One trade' installation
APPLICATIONS
- Commercial
- Corporate
- Public
- Hospitality
