W 72 WINDOW SYSTEMS
W 72 WINDOW SYSTEMS
The innovative system solution for the latest generation of sustainable, aluminium windows
Innovative, future-oriented window systems demand the highest quality with minimal energy and material consumption during manufacture and maximum efficiency for energy and costs throughout the lifetime of a product.
To ensure the unique level of heroal quality, it has always been our policy to carry out the key production steps in our own factories, applying our own expertise.
heroal has developed an innovative system solution for durable aluminium windows in line with this guiding principle, which is setting new standards – heroal W 72
INFORMAION
LEAF PROFILE DEPTH
84 mm
BRAND
Heroal
FRAME PROFILE DEPTH
72 mm
BAR PROFILE DEPTH
72 mm
PRODUCT TYPE
Windows
GLASS FILLING STRENGTH
66 mm
LEAF VISIBLE PROFILE WIDTH
33 - 67 mm
FRAME VISIBLE PROFILE WIDTH
50 - 250 mm
BAR PROFILE VISIBLE PROFILE WIDT
90 mm
MAX. LEAF WIDTHS
1.600 mm
MAX. LEAF HEIGHTS
2.800 mm
SOUNDPROOFING CATEGORIES
1–5
MAX. LEAF WEIGHT
300 kg
THERMAL INSULATION
Uf [120] = 1.3W/m²K
CASEMENT PROFI E VARIATIONS
- Push rod fitting groove [SBN]
- Plastic fitting groove [KBN]
SASH/FRAME COMBINATION VISIBLE PROFILE WIDT
74 - 254 mm
AIR PERMEABILITY
4
BURGLARY RESISTANCE
RC 4
WIND LOAD RESISTANCE
C5/B5
DRIVING RAIN TIGHTNESS
E1650
SECTIONAL DRAWINGS
PERFORMANCE CHARACTERISTICS
- Resistance to burglary
- Continuous function
- Resistance to driving rain
- Impact resistance
- Heat insulation (Uw in W/m2K) / Profile width [mm]
- Thermal insulation [Uf in W/m2K] / Profile width [mm]
- Mechanical resistance
- Operating forces
- Air permeability
- Load-bearing capacity of safety equipment
- Soundproofing class
- Wind resistance
COMPOSITE SYSTEM
Highly thermally insulated 3-chamber aluminium composite system
MODULAR INSULATION
U value adjustment through modular insulation zone construction
